2SA2126
No.7990-1/4
Applications
•
DC / DC converter, relay drivers, lamp drivers, motor drivers.
Features
•
Adoption of MBIT process.
•
High current capacitance.
•
Low collector-to-emitter saturation voltage.
•
High-speed switching.
Specifications
Absolute Maximum Ratings at Ta=25°C
Parameter Symbol Conditions Ratings Unit
Collector-to-Base Voltage V
CBO
--50 V
Collector-to-Emitter Voltage V
CES
--50 V
Collector-to-Emitter Voltage V
CEO
--50 V
Emitter-to-Base Voltage V
EBO
--6 V
Collector Current I
C
--3 A
Collector Current (Pulse) I
CP
--6 A
Base Current I
B
--600 mA
Collector Dissipation P
C
0.8 W
Tc=25°C15W
Junction Temperature Tj 150 °C
Storage Temperature Tstg --55 to +150 °C
Electrical Characteristics at Ta=25°C
Ratings
Parameter Symbol Conditions
min typ max
Unit
Collector Cutoff Current I
CBO
V
CB
=--40V, I
E
=0 --1 µA
Emitter Cutoff Current I
EBO
V
EB
=--4V, I
C
=0 --1 µA
DC Current Gain h
FE
V
CE
=--2V, I
C
=--100mA 200 560
Gain-Bandwidth Product f
T
V
CE
=--10V, I
C
=--500mA 390 MHz
Output Capacitance Cob V
CB
=--10V, f=1MHz 24 pF
Continued on next page.
Ordering number : ENN7990
21505EA TS IM TB-00000214
2SA2126
PNP Epitaxial Planar Silicon Transistor
DC / DC Converter Applications
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
