2SA1418 / 2SC3648
Rev.0 I Page 1 of 5 I www.onsemi.com
Applications
•
Color TV audio output, inverter.
Features
•
Adoption of FBET, MBIT processes.
•
High breakdown voltage and large current capacity.
•
Fast switching speed.
•
Ultrasmall size making it easy to provide high-density, small-sized hybrid IC’s.
Specifications ( ) : 2SA1418
Absolute Maximum Ratings at Ta=25°C
Parameter Symbol Conditions Ratings Unit
Collector-to-Base Voltage V
CBO
(--)180 V
Collector-to-Emitter Voltage V
CEO
(--)160 V
Emitter-to-Base Voltage V
EBO
(--)6 V
Collector Current I
C
(--)0.7 A
Collector Current (Pulse) I
CP
(--)1.5 A
Collector Dissipation P
C
500 mW
Mounted on a ceramic board (250mm
2
✕0.8mm)
1.3 W
Junction Temperature Tj 150 °C
Storage Temperature Tstg --55 to +150 °C
Marking 2SA1418 : AD
2SC3648 : CD
Ordering number : EN1788B
2SA1418 / 2SC3648
PNP / NPN Epitaxial Planar Silicon Transistors
High-Voltage Switching,
Preriver Applications
© 2011, SCILLC. All rights reserved.
Jan-2011, Rev. 0
www.onsemi.com
Publication Order Number:
2SA1418_2SC3648/D
