AT86RF233
Low Power, 2.4GHz Transceiver for ZigBee, RF4CE, IEEE
802.15.4, 6LoWPAN, and ISM Applications
PRELIMINARY DATASHEET
Features
• High Performance RF-CMOS 2.4GHz radio transceiver targeted for IEEE
®
802.15.4,
ZigBee
®
, RF4CE, 6LoWPAN, and ISM applications
• Industry leading link budget:
• Receiver sensitivity -101dBm
• Programmable TX output power from -17dBm up to +4dBm
• Ultra-low current consumption:
• DEEP_SLEEP = 0.02µA
• TRX_OFF = 300µA
• RX_ON = 11.8mA (LISTEN)
• Smart Receiving Techniques enable further current reduction in LISTEN mode
between 10 to 50% from 11.8mA
• Desensitation will enable further reduction up to 1mA
• BUSY_TX = 13.8mA (at max. transmit power)
• Ultra-low supply voltage (1.8V to 3.6V) with internal regulator
• Support for coin cell operation
• Optimized for low BoM Cost and ease of production:
• Few external components necessary (crystal, capacitors and antenna)
• Easy to use interface:
• Registers, frame buffer, and AES accessible through fast SPI
• Only two microcontroller GPIO lines necessary
• One interrupt pin from radio transceiver
• Clock output with prescaler from radio transceiver
• Radio transceiver features:
• 128-byte FIFO (SRAM) for data buffering
• Fully integrated, fast settling PLL to support Frequency Hopping
• Supports 500kHz channel spacing
• Battery monitor and Fast Wake-Up Time < 0.4msec
• Special IEEE 802.15.4™ 2011 hardware support:
• FCS computation and Clear Channel Assessment
• RSSI measurement, Energy Detection and Link Quality Indication
• MAC hardware accelerator:
• Automated acknowledgement, CSMA-CA and retransmission
• Automatic address filtering
• Automated FCS check
• Extended feature set hardware support:
• AES 128-bit hardware accelerator
• Antenna Diversity and RX/TX indication
• Supported PSDU data rates: 250kb/s, 500kb/s, 1000kb/s and 2000kb/s
• True Random Number Generation for security application
• Reduced Power Consumption modes
• Time and phase measurement support
• Industrial and extended temperature range:
• -40°C to +85°C and -40°C to +125°C
• I/O and packages:
• 32-pin Low-Profile QFN Package 5 x 5 x 0.9mm³
• RoHS/Fully Green
• Compliant to EN 300 328/440, FCC-CFR-47 Part 15, ARIB STD-66, RSS-210
• Compliant to IEEE 802.15.4 2003/2006/2011
Atmel-8351E-MCU_Wireless-AT86RF233_Datasheet_072014
