© Semiconductor Components Industries, LLC, 2015
October, 2015 − Rev. 2
1 Publication Order Number:
AX8052F143/D
AX8052F143
SoC Ultra-Low Power
RF-Microcontroller for RF
Carrier Frequencies in the
Range 27 - 1050 MHz
OVERVIEW
Features
SoC Ultra−low Power Advanced Narrow−band
RF−microcontroller for Wireless Communication
Applications
• QFN40 Package
• Supply Range 1.8 V − 3.6 V
• −40°C to 85°C
• Ultra−low Power Consumption:
♦ CPU Active Mode 150 mA/MHz
♦ Sleep Mode with 256 Byte RAM Retention and
Wake−up Timer running 900 nA
♦ Sleep Mode 4 kByte RAM Retention and Wake−up
Timer running 1.5 mA
♦ Sleep Mode 8 kByte RAM Retention and Wake−up
Timer running 2.2 mA
♦ Radio RX−mode
6.5 mA @ 169 MHz
9.5 mA @ 868 MHz and 433 MHz
♦ Radio TX−mode at 868 MHz
7.5 mA @ 0 dBm
16 mA @ 10 dBm
48 mA @ 16 dBm
AX8052
• Ultra−low Power MCU Core Compatible with Industry
Standard 8052 Instruction Set
• Down to 500 nA Wake−up Current
• Single Cycle/Instruction for many Instructions
• 64 kByte In−system Programmable FLASH
• Code Protection Lock
• 8.25 kByte SRAM
• 3−wire (1 dedicated, 2 shared) In−circuit Debug
Interface
• Three 16−bit Timers with SD Output Capability
• Two 16−bit Wakeup Timers
• Two Input Captures
• Two Output Compares with PWM Capability
• 10−bit 500 ksample/s Analog−to−Digital Converter
• Temperature Sensor
• Two Analog Comparators
• Two UARTs
• One General Purpose Master/Slave SPI
• Two Channel DMA Controller
• Multi−megabit/s AES Encryption/Decryption Engine,
supports AES−128, AES−192 and AES−256 with True
Random Number Generator (TRNG)
NOTE: The AES Engine and the TRNG require
Software Enabling and Support.
For more Details please contact
exportcontrol@axsem.com
• Ultra−low Power 10 kHz/640 Hz Wakeup Oscillator,
with Automatic Calibration against a Precise Clock
• Internal 20 MHz RC Oscillator, with Automatic
Calibration against a Precise Clock for Flexible System
Clocking
• Low Frequency Tuning Fork Crystal Oscillator for
Accurate Low Power Time Keeping
• Brown−out and Power−on−Reset Detection
High Performance Narrow−band RF Transceiver
compatible to AX5043 (FSK/MSK/4−FSK/GFSK/GMSK/
ASK/AFSK/FM/PSK)
• Receiver
♦ Carrier Frequencies from 27 to 1050 MHz
♦ Data Rates from 0.1 kbps to 125 kbps
♦ Optional Forward Error Correction (FEC)
♦ Sensitivity without FEC
−135 dBm @ 0.1 kbps, 868 MHz, FSK
−126 dBm @ 1 kbps, 868 MHz, FSK
−117 dBm @ 10 kbps, 868 MHz, FSK
−107 dBm @ 100 kbps, 868 MHz, FSK
−105 dBm @ 125 kbps, 868 MHz, FSK
−138 dBm @ 0.1 kbps, 868 MHz, PSK
−130 dBm @ 1 kbps, 868 MHz, PSK
−120 dBm @ 10 kbps, 868 MHz, PSK
−109 dBm @ 100 kbps, 868 MHz, PSK
−108 dBm @ 125 kbps, 868 MHz, PSK
www.onsemi.com
