© Semiconductor Components Industries, LLC, 2011
April, 2011 − Rev. 3
1 Publication Order Number:
CM6317/D
CM6317
EMI Filter with ESD
Protection for Data Line
Applications
Product Description
The CM6317 is an 18−bump EMI filter with ESD protection device
for data line application in a 0.4 mm pitch, 5 x 4 CSP form factor. It is
fully compliant with IEC 61000−4−2. The CM6317 is RoHS
II
compliant.
Features
• 18−Bump, 1.96 mm X 1.56 mm Footprint Chip Scale Package
• These Devices are Pb−Free and are RoHS Compliant
MARKING DIAGRAM
Device Package Shipping
†
ORDERING INFORMATION
http://onsemi.com
CSP−18
(Pb−Free)
5000/Tape & ReelCM6317
6317 = CM6317
YYWW = Date Code
XXXX = Last four digits of lot#
WLCSP18
CASE 567CG
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
ELECTRICAL SCHEMATIC
6317
YYWW
XXXX
R
GND
1 of 7 Filter Channels
+
Level 4 Level 4
