E2F E2F
2
Short Length, Shielded Sensors With
Threaded Plastic Body
■ Rugged, watertight plastic housing offers
good chemical resistance and with-
stands washdown
■ Wide operating voltages: 10 to 30 VDC
and 20 to 264 VAC
■ Operation indicator on all models
■ Short-circuit protection available on all
DC and some AC models
Ordering Information
Plastic Cylindrical Inductive Prox E2F
■ DC THREE-WIRE PREWIRED MODELS
■ AC TWO-WIRE PREWIRED MODELS
Type Size Sensing distance Part number
NO NC
Shielded M8 1.5 mm NPN E2F-X1R5E1 E2F-X1R5E2
PNP E2F-X1R5F1 E2F-X1R5F2
M12 2 mm NPN E2F-X2E1 E2F-X2E2
PNP E2F-X2F1 E2F-X2F2
M18 5 mm NPN E2F-X5E1 E2F-X5E2
PNP E2F-X5F1 E2F-X5F2
M30 10 mm NPN E2F-X10E1 E2F-X10E2
PNP E2F-X10F1 E2F-X10F2
Type Size Sensing distance Part number
NO NC
Shielded M8 1.5 mm E2F-X1R5Y1 E2F-X1R5Y2
M12 2 mm E2F-X2Y1 E2F-X2Y2
M18 5 mm E2F-X5Y1-US E2F-X5Y2-US
M30 10 mm E2F-X10Y1-US E2F-X10Y2-US
Without Short-CIrcuit Protection
Type Size Sensing distance Part number
NO NC
Shielded M18 5 mm E2F-X5Y1-53-US E2F-X5Y2-53-US
M30 10 mm E2F-X10Y1-53-US E2F-X10Y2-53-US
With Short-CIrcuit Protection
Output
configuration
