PD-97288 RevB
IRAM136-3063B
Series
30A, 600V
Integrated Power Hybrid IC for
Hi
g
h Volta
g
e Motor A
pp
lications
with Internal Shunt Resistor
Description
International Rectifier's IRAM136-3063B is a 30A, 600V Integrated Power Hybrid IC with Internal Shunt
Resistor for Appliance Motor Drives applications such air conditioning systems and compressor drivers as
well as for light industrial application. IR's technology offers an extremely compact, high performance AC
motor driver in a single isolated package to simplify design.
This advanced HIC is a combination of IR's low V
CE(on)
Punch-Through IGBT technology and the industry
benchmark 3-Phase high voltage, high speed driver in a fully isolated thermally enhanced package. A built-
in temperature monitor and over-current and over-temperature protections, along with the short-circuit
rated IGBTs and integrated under-voltage lockout function, deliver high level of protection and failsafe
operation. Using a new developed single in line package (SiP3) with heat spreader for the power die along
with full transfer mold structure minimizes PCB space and resolves isolation problems to heatsink.
Features
• Integrated Gate Drivers
• Temperature Monitor and Protection
• Overcurrent shutdown
• Low V
CE(on)
Advance Planar Super Rugged Technology
• Undervoltage lockout for all channels
• Matched propagation delay for all channels
• 5V Schmitt-triggered input logic
• Cross-conduction prevention logic
• Lower di/dt gate driver for better noise immunity
• Motor Power up to 3.3kW / 85~253 Vdc
• Fully Isolated Package, Isolation 2000V
RMS
min
Absolute Maximum Ratings
Parameter Description Value Units
V
CES
/ V
RRM
IGBT/Diode Blocking Voltage 600
V
+
Positive Bus Input Voltage 450
I
O
@ T
C
=25°C
Maximum Output Current 30
I
O
@ T
C
=100°C
RMS Phase Current (Note 1) 15
I
O
Pulsed RMS Phase Current (Note 2) 50
F
PWM
PWM Carrier Frequency 20 kHz
P
D
Power dissipation per IGBT @ T
C
=25°C
73 W
V
ISO
Isolation Voltage (1min) 2000
V
RMS
T
J
(IGBT & Diode & IC)
Maximum Operating Junction Temperature +150
T
C
Operating Case Temperature Range -20 to +100
T
STG
Storage Temperature Range -40 to +125
T Mounting torque Range (M4 screw) 0.7 to 1.17 Nm
Note 1: Sinusoidal Modulation at V
+
=400V, T
J
=150°C, F
PWM
=6kHz, Modulation Depth=0.8, PF=0.6, See Figure 3.
Note 2: t
P
<100ms; T
C
=25°C; F
PWM
=6kHz. Limited by I
BUS-ITRIP
, see Table "Inverter Section Electrical Characteristics"
V
A
°C
www.irf.com 1
