Application Report
SNOA072A–May 2004–Revised June 2010
TO-92 Packing Options / Ordering Instructions
.....................................................................................................................................................
ABSTRACT
The TO-92 is an axial leaded, flat index package. The primary shipping methods are tape-and-reel, or
radial ammo pack. These systems simplify the handling of the TO-92 for automated circuit board
assembly systems.
Contents
1 General Description ......................................................................................................... 1
1.1 Bulk Packing ........................................................................................................ 2
1.2 Taped Pack Option 1 .............................................................................................. 2
1.3 Taped Pack Option 2 .............................................................................................. 3
1.4 TO-92 Tape and Reel Dimensions .............................................................................. 4
List of Figures
1 Bulk Packing................................................................................................................. 2
2 LFT1 Tape &Reel Package Up, Flat Side Up........................................................................... 2
3 LFT2 Tape & Reel Package Down, Flat Side Up....................................................................... 2
4 LFT7 Tape & Reel Package Up, Flat Side Down....................................................................... 2
5 Other options available on request ....................................................................................... 3
6 LFT8 Tape & Reel Package Down, Flat Side Down.................................................................... 3
7 LFT3 Radial Ammo Pack Ammo Pack equivalent to option LFT1. Flat side of transistor on adhesive side
of tape. ....................................................................................................................... 3
8 Other options available on request ....................................................................................... 3
9 LFT4 Radial Ammo Pack Ammo Pack equivalent to option LFT7. Round side of transistor on adhesive
side of tape. ................................................................................................................. 3
10 NOTE: No straight leads available on taped product!.................................................................. 3
1 General Description
The TO-92 is an axial leaded, flat index package. The primary shipping methods are tape-and-reel, or
radial ammo pack. These systems simplify the handling of the TO-92 for automated circuit board
assembly systems.
NOTE: Please check with your National local representative for details specific to your product needs.
All trademarks are the property of their respective owners.
1
SNOA072A–May 2004–Revised June 2010 TO-92 Packing Options / Ordering Instructions
Submit Documentation Feedback
Copyright © 2004–2010, Texas Instruments Incorporated
