© Semiconductor Components Industries, LLC, 2016
July, 2016 − Rev. 5
1 Publication Order Number:
MC100LVEL12/D
MC100LVEL12
3.3 V ECL Low Impedance
Driver
Description
The MC100LVEL12 is a low impedance drive buffer. With two
pairs of OR/NOR outputs the device is ideally suited for high drive
applications such as memory addressing. The device is functionally
equivalent to the EL12 device and operates from a 3.3 V power supply.
With propagation delays equivalent to the EL12, the LVEL12 is
ideally suited for those applications which require the ultimate in
AC performance in a low voltage environment.
Features
• 445 ps Propagation Delay
• Dual Outputs for 25 Drive Applications
• ESD Protection:
♦ > 4 kV Human Body Model
♦ > 200 V Machine Model
• The 100 Series Contains Temperature Compensation
• PECL Mode Operating Range: V
CC
= 3.0 V to 3.8 V
with V
EE
= 0 V
• NECL Mode Operating Range: V
CC
= 0 V
with V
EE
= −3.0 V to −3.8 V
• Internal Input Pulldown Resistors
• Q Output will Default LOW with All Inputs Open or at V
EE
• Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
• Moisture Sensitivity:
♦ Level 1 for SOIC−8
♦ Level 3 for TSSOP−8
♦ For Additional Information, see Application Note AND8003/D
• Flammability Rating: UL−94 V−0 @ 0.125 in,
Oxygen Index: 28 to 34
• Transistor Count = 83 Devices
• These Devices are Pb-Free, Halogen Free and are RoHS Compliant
SOIC−8
D SUFFIX
CASE 751
*For additional marking information, refer to
Application Note AND8002/D
.
MARKING DIAGRAMS*
1
8
www.onsemi.com
KVL12
ALYW
G
1
8
(Note: Microdot may be in either location)
A = Assembly Location
L = Wafer Lot
Y = Year
W = Work Week
G = Pb-Free Package
ORDERING INFORMATION
Device Package Shipping
MC100LVEL12DG SOIC−8
(Pb-Free)
98 Units / Tube
MC100LVEL12DTG TSSOP−8
(Pb-Free)
100 Units / Tube
KV12
ALYWG
G
TSSOP−8
DT SUFFIX
CASE 948R
1
8
1
8
SOIC−8 TSSOP−8
