Semiconductor Components Industries, LLC, 2016
August, 2016 − Rev. 9
1 Publication Order Number:
MC10H016/D
MC10H016
4‐Bit Binary Counter
Description
The MC10H016 is a high-speed synchronous, pre-settable,
cascadable 4-bit binary counter. It is useful for a large number of
conversion, counting and digital integration applications.
Features
• Counting Frequency, 200 MHz Minimum
• Improved Noise Margin 150 mV
(Over Operating Voltage and Temperature Range)
• Voltage Compensated
• MECL 10K − Compatible
• Positive Edge Triggered
• These Devices are Pb-Free, Halogen Free and are RoHS Compliant
Figure 1. Pin Assignment
V
CC1
Q1
Q0
TC
PE
CE
PO
V
EE
V
CC2
Q2
Q3
CP
MR
P3
P2
P1
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
Pin assignment is for Dual-in-Line Package
Table 1. TRUTH TABLE
CE PE MR CP Function
L
H
L
H
X
X
L
L
H
H
X
X
L
L
L
L
L
H
Z
Z
Z
Z
ZZ
X
Load Parallel (P
n
to Q
n
)
Load Parallel (P
n
to Q
n
)
Count
Hold
Masters Respond; Slaves Hold
Reset (Q
n
= LOW, T
C
= HIGH)
Z = Clock Pulse (Low to High); ZZ = Clock Pulse (High to Low)
Features include assertion inputs and outputs on each of the four master/
slave counting flip-flops. Terminal count is generated internally in a manner
that allows synchronous loading at nearly the speed of the basic counter.
www.onsemi.com
10H016G
AWLYYWW
120
16
1
MC10H016P
AWLYYWWG
MARKING DIAGRAMS*
PDIP−16
P SUFFIX
CASE 648−08
16
1
A = Assembly Location
WL, L = Wafer Lot
YY, Y = Year
WW, W = Work Week
G = Pb-Fee Package
PLLC−20
FN SUFFIX
CASE 775−02
20
1
*For additional marking information, refer to
Application Note AND8002/D
.
†For information on tape and reel specifications, in-
cluding part orientation and tape sizes, please refer
to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D
.
ORDERING INFORMATION
Device Package Shipping
†
MC10H016FNR2G PLCC−20
(Pb-Free)
500/Tape & Reel
MC10H016PG PDIP−16
(Pb-Free)
25 Units/Tube
