Overview
In response to the needs of design engineers
tasked with pushing the performance
envelope, packing in a lot of connectivity
options and providing robust security in
mobile device designs, Freescale presents
the i.MX27 multimedia applications processor.
Derived from the popular i.MX21 processor
and based on the ARM926EJ-S
™
core, the
i.MX27 processor adds an H.264 D1 hardware
codec for high-resolution video processing, an
Ethernet 10/100 MAC, security, plug-and-play
connectivity and more power management
features. This rich feature set makes it an
excellent choice for video- and voice-over-IP
(V2IP) cordless and mobile phones, intelligent
remote controls, point-of-sale terminals and
many other wireless applications.
The i.MX27 multimedia applications processor
is architected with Freescale’s Smart Speed™
technology, an intelligent integrative approach
that uses hardware accelerators to offload the
CPU and a crossbar switch to bring parallelism
to the system. The result is a processor that
performs like a much higher MHz device, but
conserves power for long, long battery life.
Features
CPU Complex
• ARM926EJ-S 400 MHz core
• 16 KB L1 I-Cache and D-Cache
• 16-channel DMA
• ETM real-time debug
• Smart Speed switch
Multimedia
• MPEG-4 H.263/H.264 D1 HW codec
• Pre and post processing
• High-speed CMOS sensor interface
External Memory Interface (EMI)
• SDRAM 16/32-bit, 133 MHz
• DDR 16/32-bit, 266 MHz
• NAND flash 8/16-bit
• PSRAM support
Security Control
• Crypto accelerator
• Electronically blown fusebox
• High-assurance boot
• Security controller with encrypted
RAM storage
• Real-time OS/SW integrity checker
Advanced Power Management
•
Dynamic process temperature
compensation (DPTC)
• Active well bias
Connectivity
• 10 and 100 Mbps Ethernet/IEEE
®
802.3MAC
• USB OTG high speed, host x 2
• 3 x MMC/SD, Memory Stick-Pro
™
• PCMCIA/CF
• ATA-6 (HDD) interface
• Audio MUX
• IrDA, keypad, 1-wire
• Configurable SPI x 3, SSI/I
2
S x 2, UART x 6
Performance
• CPU complex: 400 MHz at 1.45 V, 266
MHz at 1.2 V
• System: 133 MHz
Technology
• 90 nm CMOS
• Package: 404 balls, 0.65 mm pitch
MAPBGA, 17 mm x 17 mm package
i.MX27 Multimedia Applications Processor
The i.MX Family
Freescale’s i.MX family of applications
processors delivers power to the people who
demand it: designers and users alike who want
exceptional performance and long battery life
from their mobile devices. Design engineers
capitalize on the amazing performance i.MX
processors achieve at lower clock speeds
and the high degree of integration to quickly
deliver innovative mobile devices to market.
Consumers love the lifelike video and 3-D
graphics reproduction, quick response and long
play time for hours of work and entertainment
use. Freescale gives design engineers the
power of choice with various i.MX processors,
from the i.MXS for price sensitive applications,
and i.MXL, i.MX1 and i.MX21S for mid-range
devices, to i.MX21, i.MX27, i.MX31L and
i.MX31 for high-performance mobile
multimedia devices.
The i.MX family supports a range of platforms
such as those based on the Microsoft
®
Windows
®
CE and Linux
®
operating systems
as well as a number of leading RTOSs.
i.MX27
10/100 Ethernet
ATA
I
2
C x 2
Audio Mux
2 x I
2
S/SSI
3 x CSPI
6 x UART
HS USB-OTG
Host x 2
1-Wire
3 x MMC/SD
MemStick Pro
PCMCIA/CF
JTAG/ICEM
Bootstrap
Clock Management
6 x Timer
PWM
WD Timer
Secure RTC
GPIO
DMA
IrDA
ARM926EJ-S™ Smart Speed™ Switch (MAX)
I-Cache
Internal Control
D-Cache
Bus Control
MMU
Memory Control
CPU COMPLEX
Security Control
SCC
IIM
SAHARA2
RTIC
RNGA
MEMORY INTERFACE
DDR SDRAM
NAND Flash
Vsync Flash
EIM
MULTIMEDIA ACCELERATOR
System Control
Standard
System I/O
Human Interface
Multimedia Interface
Connectivity
Internal
Exp
ansion
External
H.264
MPEG-4/H.263
Pre and Post Processing
Camera Interface
8 x 8 Keypad
LCD Control
Smart LCD
Inherited from i.MX21
New or Enhanced from i.MX21
