K4S56163LF - X(Z)E/N/G/C/L/F
February 2004
Mobile-SDRAM
• 2.5V power supply.
• LVCMOS compatible with multiplexed address.
• Four banks operation.
• MRS cycle with address key programs.
-. CAS latency (1, 2 & 3).
-. Burst length (1, 2, 4, 8 & Full page).
-. Burst type (Sequential & Interleave).
• EMRS cycle with address key programs.
• All inputs are sampled at the positive going edge of the system
clock.
• Burst read single-bit write operation.
• Special Function Support.
-. PASR (Partial Array Self Refresh).
-. Internal TCSR (Temperature Compensated Self Refresh)
• DQM for masking.
• Auto refresh.
• 64ms refresh period (8K cycle).
• Commercial Temperature Operation (-25°C ~ 70°C).
• Extended Temperature Operation (-25°C ~ 85°C).
• 54Balls BOC with 0.8mm ball pitch
( -X : Leaded, -Z : Lead Free).
FEATURES
The K4S56163LF is 268,435,456 bits synchronous high data
rate Dynamic RAM organized as 4 x 4,196,304 words by 16 bits,
fabricated with SAMSUNG's high performance CMOS technol-
ogy. Synchronous design allows precise cycle control with the
use of system clock and I/O transactions are possible on every
clock cycle. Range of operating frequencies, programmable
burst length and programmable latencies allow the same device
to be useful for a variety of high bandwidth, high performance
memory system applications.
GENERAL DESCRIPTION
ORDERING INFORMATION
- X(Z)E/N/G : Normal / Low / Low Power, Extended Temperature(-25°C ~ 85°C)
- X(Z)C/L/F : Normal / Low / Low Power, Commercial Temperature(-25°C ~ 70°C)
NOTES :
1. In case of 40MHz Frequency, CL1 can be supported.
2. Samsung are not designed or manufactured for use in a device or system that is used under circumstance in which human life is potentially at stake.
Please contact to the memory marketing team in samsung electronics when considering the use of a product contained herein for any specific
purpose, such as medical, aerospace, nuclear, military, vehicular or undersea repeater use.
Part No. Max Freq. Interface Package
K4S56163LF-X(Z)E/N/G/C/L/F75 133MHz(CL=3)
LVCMOS
54 BOC
Leaded (Lead Free)
K4S56163LF-X(Z)E/N/G/C/L/F1H 105MHz(CL=2)
K4S56163LF-X(Z)E/N/G/C/L/F1L
105MHz(CL=3)
*1
4M x 16Bit x 4 Banks Mobile SDRAM in 54BOC
