Document Number: MPXA6115A
Rev 7, 05/2011
Freescale Semiconductor
Technical Data
© Freescale Semiconductor, Inc., 2007-2011. All rights reserved.
High Temperature Accuracy
Integrated Silicon Pressure Sensor
for Measuring Absolute Pressure,
On-Chip Signal Conditioned,
Temperature Compensated and
Calibrated
The MPXxx6115A series sensor integrates on-chip, bipolar op amp
circuitry and thin film resistor networks to provide a high output signal and
temperature compensation. The small form factor and high reliability of on-
chip integration make the pressure sensor a logical and economical choice
for the system designer.
The MPXxx6115A series piezoresistive transducer is a state-of-the-art,
monolithic, signal conditioned, silicon pressure sensor. This sensor combines
advanced micromachining techniques, thin film metallization, and bipolar
semiconductor processing to provide an accurate, high level analog output
signal that is proportional to applied pressure.
Features
• Resistant to High Humidity and Common Automotive Media
• Improved Accuracy at High Temperature
• Available in Small and Super Small Outline Packages
• 1.5% Maximum Error over 0° to 85°C
• Ideally suited for Microprocessor or Microcontroller-Based Systems
• Temperature Compensated from -40° to +125°C
• Durable Thermoplastic (PPS) Surface Mount Package
ORDERING INFORMATION
Device Name
Package
Option
Case No.
# of Ports Pressure Type
Device
Marking
None Single Dual Gauge Differential Absolute
Small Outline Package (MPXA6115A Series)
MPXA6115A6U Rails 482 • • MPXA6115A
MPXA6115A6T1 Tape and Reel 482 • • MPXA6115A
MPXA6115AC6U Rails 482A • • MPXA6115A
MPXA6115AC6T1 Tape and Reel 482A • • MPXA6115A
MPXA6115AC7U Rails 482C • • MPXA6115A
Small Outline Package (Media Resistant Gel) (MPXAZ6115A Series)
MPXAZ6115A6U Rails 482 • • MPXAZ6115A
MPXAZ6115AC6U Rails 482A • • MPXAZ6115A
MPXAZ6115AC6T1 Tape and Reel 482A • • MPXAZ6115A
MPXAZ6115AP Trays 1369 • • MPXAZ6115A
MPXAZ6115APT1 Tape and Reel 1369 • • MPXAZ6115A
Super Small Outline Package (MPXH6115A Series)
MPXH6115A6U Rails 1317 • • MPXH6115A
MPXH6115A6T1 Tape and Reel 1317 • • MPXH6115A
MPXH6115AC6U Rails 1317A • • MPXH6115A
MPXH6115AC6T1 Tape and Reel 1317A • • MPXH6115A
MPXA6115A
Series
MPXH6115A
MPXHZ6115A
15 to 115 kPa (2.2 to 16.7 psi)
0.2 to 4.8 V Output
MPXAZ6115A
Application Examples
• Aviation Altimeters
• Industrial Controls
• Engine Control/Manifold Absolute
Pressure (MAP)
• Weather Station and Weather
Reporting Device Barometers
