Hersteller:
TE Connectivity
Kategorie:
Thermistor
Fallpaket
1206
Beschreibung:
PTC Resettable Fuse 1.5A(hold) 3A(trip) 6VDC 100A 0.8W 0.3s 0.04Ω SMD Solder Pad 1206 T/R

Aktualisierte Uhrzeit: 2025-04-09 02:59:49 (UTC+8)

NANOSMDC150F-2 datasheet.datasheet_page 1

Technische Daten

NANOSMDC150F-2 datasheet.datasheet_page 2

NANOSMDC150F-2 Anwendungshinweis

Seite:von 2

PDF herunterladen

Neu laden

herunterladen

CorporateInformation
AboutTE
Investors
NewsRoom
SupplierPortal
Careers
QuickLinks
DistributorInventory
ProductCrossReference
Documents&Drawings
ProductComplianceSupportCenter
SiteMap
CustomerSupport
EmailorChatWithUs
FindaPhoneNumber
KnowledgeBase
ManageYourAccount
KeepMeInformed

Products Industries Resources AboutTE MyAccount Innovation SupportCenter
QuickLinks
Pricing&Availability
SearchforTooling
ProductFeatureSelector
ContactUsAboutThisProduct
AddtoMyPartList RequestSample FindSimilarProducts BuyProduct
NANOSMDC150F2ProductDetails
NANOSMDC150F2
(RF1358000)
TEInternalNumber:RF1358000
Active
PolySwitchResettableDevices
AlwaysEURoHS/ELVCompliant(StatementofCompliance)
ProductHighlights:
SurfaceMountApplication
VmaxOperating=6V
Vmax=6V
Imax=100A
FamilyName=nanoSMD
ViewallFeatures
Documentation&AdditionalInformation
ProductDrawings:
nanoSMDC150F(PDF,English)
CatalogPages/DataSheets:
CPCATALOG2011SURFACEMOUNT(PDF,English)
ProductSpecifications:
nanoSMDC150F(PDF,English)
ApplicationSpecifications:
NoneAvailable
InstructionSheets:
NoneAvailable
CADFiles:
NoneAvailable
ListallDocuments
RelatedProducts:
Tooling
ProductFeatures(PleaseusetheProductDrawingforalldesignactivity)
ProductTypeFeatures:
FamilyName=nanoSMD
CSAFileNumber=CA78165
ElectricalCharacteristics:
VmaxOperating(V)=6
Vmax(V)=6
Imax(A)=100
IH(RoomTemperature)(A)=1.5
IT(RoomTemperature)(A)=3.00
Rmin(Ω)=0.04
R1Max[PostTrip](Ω)=0.11
PowerDissipation(Max)(W)=0.8
TerminationFeatures:
Construction=SurfaceMount
ConfigurationFeatures:
FormFactor(inches)=1206
FormFactor(mm)=3216
IndustryStandards:
RoHS/ELVCompliance=RoHScompliant,ELVcompliant
LeadFreeSolderProcesses=Reflowsoldercapableto245°C,
Reflowsoldercapableto260°C
RoHS/ELVComplianceHistory=AlwayswasRoHScompliant
ULFileNumber=E74889
TUVCertificateNo.=R72041439
Environmental:
OperatingTemperature(Max.)(°C)=85
Operation/Application:
Application=SurfaceMount
PackagingFeatures:
PackagingMethod=Tape&Reel
Other:
Brand=Raychem
