© 2010 Fairchild Semiconductor Corporation DS012177.fm www.fairchildsemi.com
January 2010
NC7SZ66
Low Voltage Single SPST Normally Open Bus Switch
General Description
The NC7SZ66 is a ultra high-speed (UHS) CMOS compatible
single-pole/single-throw (SPST) bus switch. The LOW On
Resistance of the switch allows inputs to be connected to out-
puts with minimal propagation delay and without generating
additional ground bounce noise. The device is organized as a 1-
bit switch with a switch enable (OE) signal. When OE is HIGH,
the switch is on and Port A is connected to Port B. When OE is
LOW, the switch is open and a high-impedance state exists
between the two ports.
Features
■ Space saving SOT23 or SC70 5-lead package
■ Ultra small MicroPak™ Pb-Free leadless package
■ Broad V
CC
Operating Range 1.65V–5.5V
■ Rail-to-rail signal handling
■ 5Ω switch connection between two ports
■ Minimal propagation delay through the switch
■ Low I
CC
■ Zero bounce in flow-through mode
■ Control input compatible with CMOS input levels
Ordering Code:
Pb-Free package per JEDEC J-STD-020B.
MicroPak™ is a trademark of Fairchild Semiconductor Corporation.
Order Package Product Code
Package Description Supplied As
Number Number Top Mark
NC7SZ66M5X MA05B 7Z66 5-Lead SOT23, JEDEC MO-178, 1.6mm 3k Units on Tape and Reel
NC7SZ66P5X MAA05A Z66 5-Lead SC70, EIAJ SC-88a, 1.25mm Wide 3k Units on Tape and Reel
NC7SZ66L6X MAC06 EE Pb-Free 6-Lead MicroPak, 1.0mm Wide 5k Units on Tape and Reel
