January 2006
NC7WZ02 TinyLogic
®
UHS Dual 2-Input NOR Gate
©2006 Fairchild Semiconductor Corporation
1
www.fairchildsemi.com
NC7WZ02 Rev. 1.0.0
NC7WZ02
TinyLogic
®
UHS Dual 2-Input NOR Gate
General Description
The NC7WZ02 is a dual 2-Input NOR Gate from Fair-
child’s Ultra High Speed Series of TinyLogic
®
. The
device is fabricated with advanced CMOS technology to
achieve ultra high speed with high output drive while
maintaining low static power dissipation over a very
broad V
CC
operating range. The device is specified to
operate over the 1.65V to 5.5V V
CC
range. The inputs
and output are high impedance when V
CC
is 0V. Inputs
tolerate voltages up to 7V independent of V
CC
operating
voltage.
Features
■
Space saving US8 surface mount package
■
MicroPak™ Pb-Free leadless package
■
Ultra High Speed: t
PD
2.4ns typ into 50pF at 5V V
CC
■
High Output Drive: ±24mA at 3V VCC
■
Broad VCC Operating Range: 1.65V to 5.5V
■
Matches the performance of LCX when operated at
3.3V V
CC
■
Power down high impedance inputs/output
■
Overvoltage tolerant inputs facilitate 5V to 3V
translation
■
Patented noise/EMI reduction circuitry implemented
Ordering Information
Pb-Free package per JEDEC J-STD-020B.
Logic Symbol
Order
Number
Package
Number
Package Code
Top Mark Package Description Supplied As
NC7WZ02K8X MAB08A WZ02 8-Lead US8, JEDEC MO-187,
Variation CA 3.1mm Wide
3k Units on Tape and
Reel
NC7WZ02L8X MAC08A P5 Pb-Free 8-Lead MicroPak,
1.6 mm Wide
5k Units on Tape and
Reel
A
1
IEEE/IEC
≥1
Y
1
B
1
A
2
B
2
Y
2
TinyLogic
®
is a registered trademark of Fairchild Semiconductor Corporation. MicroPak™ is a trademark of Fairchild Semiconductor Corporation.
