© 2005 Fairchild Semiconductor Corporation DS500268 www.fairchildsemi.com
April 2000
Revised February 2005
NC7WZ08 TinyLogic£ UHS Dual 2-Input AND Gate
NC7WZ08
TinyLogic£ UHS Dual 2-Input AND Gate
General Description
The NC7WZ08 is a dual 2-Input AND Gate from Fairchild's
Ultra High Speed Series of TinyLogic
£
. The device is fabri-
cated with advanced CMOS technology to achieve ultra
high speed with high output drive while maintaining low
static power dissipation over a very broad V
CC
operating
range. The device is specified to operate over the 1.65V to
5.5V V
CC
range. The inputs and output are high impedance
when V
CC
is 0V. Inputs tolerate voltages up to 7V indepen-
dent of V
CC
operating voltage.
Features
■ Space saving US8 surface mount package
■ MicroPak
¥
Pb-Free leadless package
■ Ultra High Speed; t
PD
2.5 ns Typ into 50 pF at 5V V
CC
■ High Output Drive;
r
24 mA at 3V V
CC
■ Broad V
CC
Operating Range; 1.65V to 5.5V
■ Matches the performance of LCX when operated at
3.3V V
CC
■ Power down high impedance inputs/output
■ Overvoltage tolerant inputs facilitate 5V to 3V translation
■ Patented noise/EMI reduction circuitry implemented
Ordering Code:
Pb-Free package per JEDEC J-STD-020B.
Note 1: “_NL” indicates lead-free product (per JEDEC J-STD-020B). Device is available in Tape and Reel only.
TinyLogic
£
is a registered trademark of Fairchild Semiconductor Corporation.
MicroPak
¥
is a trademark of Fairchild Semiconductor Corporation.
Product
Package Description Supplied AsOrder Package Code
Number Number Top Mark
NC7WZ08K8X MAB08A WZ08 8-Lead US8, JEDEC MO-187, Variation CA 3.1mm
Wide
3k Units on Tape and Reel
NC7WZ08K8X_NL
(Note 1)
MAB08A WZ08 Pb-Free 8-Lead US8, JEDEC MO-187, Variation CA
3.1mm Wide
3k Units on Tape and Reel
NC7WZ08L8X MAC08A N4 Pb-Free 8-Lead MicroPak, 1.6 mm Wide 5k Units on Tape and Reel
