September 2009
© 1999 Fairchild Semiconductor Corporation www.fairchildsemi.com
NC7WZ16 • Rev. 1.0.3
NC7WZ16 — TinyLogic
®
UHS Dual Buffer
NC7WZ16
TinyLogic
®
UHS Dual Buffer
Features
Ultra-High Speed: t
PD
2.4ns (Typical) into 50pF at
5V V
CC
High Output Drive: ±24mA at 3V V
CC
Broad V
CC
Operating Range: 1.65V to 5.5V
Matches Performance of LCX when Operated at
3.3V V
CC
Power Down High-Impedance Inputs/Outputs
Over-Voltage Tolerance Inputs Facilitate 5V to 3V
Translation
Proprietary Noise/EMI Reduction Circuitry
Ultra-Small MicroPak™ Packages
Space-Saving SC70 Package
Description
The NC7WZ16 is a dual buffer from Fairchild’s Ultra-
High Speed Series of TinyLogic
®
. The device is
fabricated with advanced CMOS technology to achieve
ultra-high speed with high output drive while maintaining
low static power dissipation over a very broad V
CC
operating range. The device is specified to operate over
the 1.65V to 5.5V V
CC
range. The inputs and outputs are
high impedance when V
CC
is 0V. Inputs tolerate
voltages up to 7V independent of V
CC
operating voltage.
Ordering Information
Part Number Top Mark
Eco Status
Package Packing Method
NC7WZ16P6X Z16 RoHS 6-Lead SC70, EIAJ SC-88a, 1.25mm Wide
3000 Units on
Tape & Reel
NC7WZ16L6X C7 RoHS 6-Lead MicroPak™, 1.00mm Wide
5000 Units on
Tape & Reel
NC7WZ16FHX
(Preliminary)
C7 Green
6-Lead, MicroPak2, 1x1mm Body, .35mm
Pitch
5000 Units on
Tape & Reel
For Fairchild’s definition of Eco Status, please visit: http://www.fairchildsemi.com/company/green/rohs_green.html.
