www.pericom.com PS8429F 10/23/13 All trademarks are property of their respective owners.
PI3C34X245
Block Diagram
BE1
A7
A0
B7
B0
BE2
A15
A8
B15
B8
BE3
A23
A16
B23
B16
BE4
A31
A24
B31
B24
Pin Configuration
NC
1
2
3
4
5
6
7
8
9
GND
10
11
12
13
14
15
16
17
18
19
20
GND
BE1
80
79
78
77
76
75
VCC
74
73
72
71
70
69
68
67
66
65
64
63
62
B15
61
A0
A1
A2
A3
A4
A5
A6
A7
NC
A8
A9
A10
A11
A12
A13
A14
A15
B14
B13
B12
B11
B10
B9
B8
BE2
VCC
B0
B1
B2
B3
B4
B5
B6
B7
NC
21
22
23
24
25
26
27
28
29
GND
30
31
32
33
34
35
36
37
38
39
40
GND
BE3
60
59
58
57
56
55
VCC
54
53
52
51
50
49
48
47
46
45
44
43
42
B31
41
A16
A17
A18
A19
A20
A21
A22
A23
NC
A24
A25
A26
A27
A28
A29
A30
A31
B30
B29
B28
B27
B26
B25
B24
BE4
VCC
B16
B17
B18
B19
B20
B21
B22
B23
Description
Pericom Semiconductor’s PI3C34X245 is a 2.5V or 3.3V, 32-bit,
2-port bus switch designed with a low On-Resistance (5-ohms)
allowing inputs to be connected directly to outputs. e bus
switch creates no additional propagational delay or additional
ground bounce noise. e switches are turned ON by the Bus En-
able (BE) input signal. It is very useful in switching signals that
have high bandwidth (>400 MHz).
Features
Near-Zero propagation delay
5-ohm switches connect inputs to outputs
2.5V Supply Voltage Operation
Permits Hot Insertion
Capable of Hot-Swapping
5V I/O Tolerant
High Bandwidth Operation (>400 MHz)
Packaging (Pb-free & Green):
80-pin 150-mil wide plastic BQSOP (B)
2.5V/3.3V, High Bandwidth, Hot Insertion
32-Bit, 2-Port, Bus Switch
Pin Description
Pin Name Description
BEn Bus Enable Input (Active LOW)
A0 – A31 Bus A
B0 – B31 Bus B
13-0159
