Intellimod™ L1-Series
Three Phase
IGBT Inverter + Brake
150 Amperes/600 Volts
PM150RL1A060
1
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
www.pwrx.com
03/10 Rev. 1
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
£ Complete Output Power
Circuit
£ Gate Drive Circuit
£ Protection Logic
– Short Circuit
– Over Temperature
Using On-chip
Temperature Sensing
– Under Voltage
£ Low Loss Using Full Gate
CSTBT
™
IGBT Chip
Applications:
£ Inverters
£ UPS
£ Motion/Servo Control
£ Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM150RL1A060 is a 600V,
150 Ampere Intellimod™ Intelligent
Power Module.
Type Current Rating V
CES
Amperes Volts (x 10)
PM 150 60
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
PU
Br
VWNB
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
V
CC
S
I
GND GND
OUT
F
O
IN
OT
U
N
F
O
V
NC
W
N
V
N1
V
N
V
WPC
W
P
W
FO
V
WP1
V
VPC
V
P
V
FO
V
VP1
V
UPC
U
P
U
FO
V
UP1
1.5k 1.5k1.5k1.5k
AD
AE
Z
T
AA
C
X
N
P
B U V W
1 5 9 19
19 FO
17 VN
14 VN1
11 W P
8 VVP1
2 UFO
6 VFO
5 VVPC
3 UP
7 VP
9 VWPC
10 WFO
12 VWP1
1 VUPC
4 VUP1
16 UN
15 Br
18 W
N
13 VNC
TERMINAL
CODE
Q
R
V
Y
Y
L
W
P A
DE
GF
H J J J
K
K
K
K
U
L
U U
S
N
M
B
AB
(6 PLACES)
AC
(2 PLACES)
AF
AG
(2 PLACES)
F
Outline Drawing and Circuit Diagram
Dimensions Inches Millimeters
A 4.72 120.0
B 2.17 55.0
C 0.63 16.0
D 4.17 106.0
E 0.28 7.0
F 0.78 19.75
G 2.62 66.5
H 0.13 3.25
J 0.63 16.0
K 0.08 2.0
L 0.47 12.0
M 1.08 27.5
N 0.57 13.5
P 0.43 11.0
Q 0.42 10.75
R 1.29 32.75
Dimensions Inches Millimeters
S 0.46 11.75
T 0.86+0.04/0.02 22.0+1.0/-0.5
U 0.91 23.0
V 0.57 14.5
W 1.26 32.0
X 1.24 31.5
Y 0.69 17.5
Z Screw Depth 12
AA 0.51 13.0
AB M5 Metric M5
AC 0.22 Dia. 5.5 Dia.
AD 0.28 7.0
AE 0.12 3.0
AF 0.02 Sq. 0.5 Sq.
AG 0.10 Dia. 2.5 Dia.
