Features
Lowprofile:2.0x1.6x0.4inches(50.8x40.6x10.2mm)
2：1wideinputvoltageof9-18,18-36and36-75VDC
4：1ultrawideinputvoltageof9-36and18-75VDC
20Wattsoutputpower
Inputtooutput isolation:1600Vdc,min
Operatingcasetemperaturerange:100℃ max
Over-currentprotection,auto-recovery
Outputovervoltageprotection
ISO9001certifiedmanufacturingfacilities
UL60950-1,EN60950-1andIEC60950-1licensed
CEMarkmeet2006/95/EC,93/68/EECand2004/108/EC
ComplianttoRoHSEUdirective2002/95/EC
Applications
Distributedpowerarchitectures
Communicationsequipment
Computerequipment
PXE20 Single Output DC/DC Converters
9 to 75 Vdc input, 3.3 to 15 Vdc Single Output, 20W
General Description
ThePXE20singleoutputseriesoffers20Wattsofoutputpowerfroma2x1.6x0.4inchpackage.ThePXE20-xxSxx
modelshavea2:1wideinputvoltageof9-18,18-36and36-75VDC.ThePXE20-xxWSxxmodelshavea4:1wide
inputvoltageof9-36and18-75VDC.
Table of contents
Absolute Maximum Rating P2 External trim adjustment P7
Output Specifications P2 Characteristic curve P9
Input Specifications P3 Test configurations P26
General Specifications P3 Part number structure P27
Thermal Consideration P4 Mechanical data P27
Output over current protection P6 Safety and installation instruction P28
Short circuit protection P6 MTBF and Reliability P28
Solder and Reflow consideration P7
