Code
Designation
Type L W H I1 I2
RC1005(1/16W )
RC1608(1/10W)
RC2012( 1/8W )
RC3216( 1/4W)
RC3225( 1/4W )
RC5025( 1/2W )
RC6432( 1W )
1.00±0.05
1.60±0.10
2.00±0.20
3.20±0.20
3.20±0.20
5.00±0.15
6.30±0.15
0.50±0.05
0.80±0.15
1.25±0.15
1.60±0.15
2.55±0.20
2.50±0.15
3.20±0.15
0.35±0.05
0.45±0.10
0.50±0.10
0.55±0.10
0.55±0.10
0.55±0.15
0.55±0.15
0.20±0.10
0.30±0.20
0.40±0.20
0.45±0.20
0.45±0.20
0.60±0.20
0.60±0.20
0.25±0.10
0.35±0.10
0.35±0.20
0.40±0.20
0.40±0.20
0.60±0.20
0.60±0.20
STRUTURE AND DIMENSIONS
PARTS NUMBERING SYSTEM
TTHHIICCKK FFIILLMM CCHHIIPP RREESSIISSTTOORRSS
Glass Coating
Alumina Substrate
Special Plating
H
L
W
l
2
l
2
l
1
l
1
Thick-Film Electrode
RuO
2
Type Resistor
Chip
Resistor
-RC
:
Glass Coating
-RH
:
Polymer Epoxy
Coating
RC
1
Dimension
(mm)
1005
:
1.0×0.5
1608
:
1.6×0.8
2012
:
2.0×1.25
3216
:
3.2×1.6
3225
:
3.2×2.55
5025
:
5.0×2.5
6432
:
6.4×3.2
2012
2
Resistance
Tolerance
D
:
±0.5%
F
:
±1%
G
:
± 2%
J
:
± 5%
K
:
±10%
J
3
Resistance Value Marking
3 or 4 digit coding system.
(
IEC Coding System)
Resistance Value
1st two digits represents
Significant figures.
The last digit represents
the number of zeros.
Jumper chip is
represented as 000
100
4
Packaging Code
AS
:
Tape
Packaging. 13”
CS
:
Tape
Packaging. 7”
ES
:
Tape
Packaging. 10”
BS
:
Bulk
Packaging.
CS
5
(
UNIT
:
mm
)
