Semiconductor Group 1
PNP Silicon Transistors for High Voltages SMBTA 92
SMBTA 93
Maximum Ratings
Type Ordering Code
(tape and reel)
Marking
Package
1)
Pin Configuration
SMBTA 92
SMBTA 93
Q68000-A6479
Q68000-A6483
s2D
s2E
SOT-23
B E C
1 2 3
1)
For detailed information see chapter Package Outlines.
2)
Package mounted on epoxy pcb 40 mm × 40 mm × 1.5 mm/6 cm
2
Cu.
Parameter Symbol Values Unit
Emitter-base voltage VEB0
Collector-base voltage VCB0
Junction temperature Tj ˚C
Total power dissipation, T
S = 74 ˚C Ptot mW
Storage temperature range T
stg
Collector-emitter voltage VCE0 V
Thermal Resistance
Junction - ambient
2)
Rth JA ≤ 280 K/W
5
360
150
– 65 … + 150
300 200
SMBTA 92 SMBTA 93
Collector current IC mA500
Base current I
B 100
Junction - soldering point R
th JS ≤ 210
300 200
● High breakdown voltage
● Low collector-emitter saturation voltage
● Complementary types: SMBTA 42, SMBTA 43 (NPN)
5.91
