Application Report
SLLA300–February 2010
FlatLink™ Data Transmission System Using
SN75LVDS83B/SN75LVDS82/SN75LVDS86A
Ankur Verma ......................................................................................... HPA-ICP-High Speed Interface
ABSTRACT
This application report presents various system designs possible using the FlatLink™ transmitter:
SN75LVDS83B, and the FlatLink™ receivers: SN75LVDS82 and SN75LVDS86A. These are low-voltage
differential signaling (LVDS) serializer/deserializer (SerDes) devices commonly used to transmit video data
to liquid crystal display (LCD) panels. The application report starts with an introduction of the FlatLink™
system, followed by the input and output data timing diagrams, and then finally shows different system
designs with the help of system diagrams.
Contents
1 Introduction .................................................................................................................. 2
2 TTL Input Data .............................................................................................................. 2
3 LVDS Output Data .......................................................................................................... 3
4 System Diagrams ........................................................................................................... 5
4.1 24-Bit Color Host to 24-Bit LCD Panel Application with 2 MSB Over 4
th
Channel ........................ 5
4.2 24-Bit Color Host to 24-Bit LCD Panel Application with 2 LSB Over 4
th
Channel ......................... 6
4.3 18-Bit Color Host to 18-Bit Color LCD Panel Display Application ........................................... 7
4.4 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Linear) ................................. 8
4.5 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Non-linear) ............................ 9
4.6 24-Bit Color Host to 18-Bit Color LCD Panel Display Application .......................................... 10
4.7 18-Bit Color Host to 18-Bit Color LCD Panel Display Application .......................................... 11
4.8 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Linear) ............................... 12
4.9 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Non-linear) ........................... 13
4.10 24-Bit Color Host to 18-Bit Color LCD Panel Display Application .......................................... 14
5 Power Up/Down Sequence .............................................................................................. 15
List of Figures
1 TTL Input Data Timing Diagram for XGA (1024 x 768)................................................................ 3
2 LVDS Output Data Timing Diagram...................................................................................... 4
3 24-Bit Color Host to 24-Bit LCD Panel Application with 2 MSB Over 4
th
Channel ................................. 5
4 24-Bit Color Host to 24-Bit LCD Panel Application with 2 LSB Over 4
th
Channel ................................. 6
5 18-Bit Color Host to 18-Bit Color LCD Panel Display Application ................................................... 7
6 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Linear) ......................................... 8
7 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Non-linear) .................................... 9
8 24-Bit Color Host to 18-Bit Color LCD Panel Display Application .................................................. 10
9 18-Bit Color Host to 18-Bit Color LCD Panel Display Application .................................................. 11
10 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Linear) ........................................ 12
11 12-Bit Color Host to 18-Bit Color LCD Panel Display Application (Non-linear) ................................... 13
12 24-Bit Color Host to 18-Bit Color LCD Panel Display Application .................................................. 14
13 Power Up/Down Sequence .............................................................................................. 15
FlatLink is a trademark of Texas Instruments.
1
SLLA300–February 2010 FlatLink™ Data Transmission System Using
SN75LVDS83B/SN75LVDS82/SN75LVDS86A
Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated
