www.ti.com
FEATURES
TQFN PACKAGE
(TOP VIEW)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
45
21
22
23
24
25
26
27
28
31
30
29
49
50
51
56
55
54
53
52
40
39
38
37
36
35
34
33
32
44
43
42
41
48
46
47
GND
A
0
A
1
V
CC
NC
GND
A
2
A
3
GND
V
CC
A
4
A
5
GND
A
6
A
7
GND
SEL
V
CC
A
8
A
9
0B
1
1B
1
0B
2
1B
2
GND
2B
1
3B
1
2B
2
3B
2
GND
V
CC
4B
1
5B
1
4B
2
5B
2
GND
6B
1
7B
1
6B
2
7B
2
V
CC
GND
NC
GND
NC
NC
V
CC
GND
GND
8B
1
9B
1
GND
8B
2
9B
2
V
CC
GND
APPLICATIONS
DESCRIPTION/ORDERING INFORMATION
TS3DV520
5-CHANNEL DIFFERENTIAL 10:20 MULTIPLEXER SWITCH
FOR DVI/HDMI APPLICATIONS
SCDS197C – DECEMBER 2005 – REVISED APRIL 2006
• Compatible With HDMI v1.2a (Type A) DVI 1.0
High-Speed Digital Interface
– Wide Bandwidth of Over 1.65 Gbps
(Bandwidth 2.4 Gbps Typ)
– 165-MHz Speed Operation
– Serial Data Stream at 10 × Pixel Clock Rate
– Supports All Video Formats up to 1080p
and SXGA (1280 × 1024 at 75 Hz)
– Total Raw Capacity 4.95 Gbps (Single Link)
– HDCP Compatible
• Low Crosstalk (X
TALK
= –41 dB Typ)
• Low Bit-to-Bit Skew (t
sk(o)
= 0.1 ns Max)
• Low and Flat ON-State Resistance
(r
on
= 6 Ω Max, r
on(flat)
= 0.5 Ω Typ)
• Low Input/Output Capacitance
(C
ON
= 7.8 pF Typ)
• Rail-to-Rail Switching on Data I/O Ports
(0 to 5 V)
• V
CC
Operating Range From 3 V to 3.6 V
• I
off
Supports Partial-Power-Down Mode
Operation
• Latch-Up Performance Exceeds 100 mA Per
JESD 78, Class II
• ESD Performance Tested Per JESD 22
– 2000-V Human-Body Model
(A114-B, Class II)
NC – No internal connection
– 1000-V Charged-Device Model (C101)
• DVI/HDMI Signal Switching
• Differential DVI, HDMI Signal Multiplexing for
Audio/Video Receivers and High-Definition
Televisions (HDTVs)
The TS3DV520 is a 20-bit to 10-bit multiplexer/demultiplexer digital video switch with a single select (SEL) input.
SEL controls the data path of the multiplexer/demultiplexer. The device provides five differential channels for
digital video signal switching.
This device provides low and flat ON-state resistance (r
on
) and excellent ON-state resistance match. Low
input/output capacitance, high bandwidth, low skew, and low crosstalk among channels make this device
suitable for various digital video applications, such as DVI and HDMI.
This device is fully specified for partial-power-down applications using I
off
. The I
off
feature ensures that damaging
current will not backflow through the device when it is powered down. The device has isolation during power off.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Copyright © 2005–2006, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
