ATWINC3400-MR210
IEEE 802.11 b/g/n Link Controller with Integrated Low
Energy Bluetooth 4.0
PRELIMINARY DATASHEET
Description
Atmel
®
ATWINC3400-MR210 is an IEEE
®
802.11 b/g/n RF/Baseband/MAC link
controller and Low Energy Bluetooth
®
4.0 compliant module optimized for low-power
mobile applications. The ATWINC3400-MR210 supports single stream 1x1 802.11n
mode providing up to 72Mbps PHY rate. The ATWINC3400-MR210 module features
small form factor while fully integrating Power Amplifier, LNA, Switch, Power
Management, and Chip Antenna. It also feature an on-chip microcontroller and
integrated flash memory for system software. Implemented in 65nm CMOS
technology, the ATWINC3400-MR210 offers very low power consumption while
simultaneously providing high performance and minimal bill of materials.
The ATWINC3400-MR210 utilizes highly optimized 802.11-Bluetooth coexistence
protocols. The ATWINC3400-MR210 provides multiple peripheral interfaces including
UART, SPI, and I
2
C. The only external clock sources needed for the ATWINC3400-
MR210 is a 32.768kHz clock for sleep operation.
Features
IEEE 802.11
IEEE 802.11 b/g/n RF/PHY/MAC SOC
IEEE 802.11 b/g/n (1x1) for up to 72Mbps PHY rate
Single spatial stream in 2.4GHz ISM band
Integrated PA and T/R switch
Integrated chip antenna
Superior sensitivity and range via advanced PHY signal processing
Advanced equalization and channel estimation
Advanced carrier and timing synchronization
Wi-Fi Direct
®
and Soft-AP support
Supports IEEE 802.11 WEP, WPA, WPA2 security
Supports China WAPI security
Superior MAC throughput via hardware accelerated two-level A-MSDU/A-MPDU
frame aggregation and block acknowledgement
On-chip memory management engine to reduce host load
SPI, I
2
C, and UART host interfaces
