DS160 (v1.2) June 24, 2009 www.xilinx.com
Advance Product Specification 1
© 2009 Xilinx, Inc. XILINX, the Xilinx logo, Virtex, Spartan, ISE, and other designated brands included herein are trademarks of Xilinx in the United States and other countries.
PCI, PCIe and PCI Express are trademarks of PCI-SIG and used under license. All other trademarks are the property of their respective owners.
General Description
The Spartan®-6 family provides leading system integration capabilities with the lowest total cost for high-volume applications. The
thirteen-member family delivers expanded densities ranging from 3,400 to 148,000 logic cells, with half the power consumption of previous
Spartan families and faster, more comprehensive connectivity. Built on a mature 45 nm low-power copper process technology that delivers
the optimal balance of cost, power, and performance, the Spartan-6 family offers a new, more efficient, dual-register 6-input look-up table
(LUT) logic and a rich selection of built-in system-level blocks. These include 18 Kb (2 x 9 Kb) block RAMs, second generation DSP48A1
slices, SDRAM memory controllers, enhanced mixed-mode clock management blocks, SelectIO™ technology, power-optimized high-
speed serial transceiver blocks, PCI Express™ compatible Endpoint blocks, advanced system-level power management modes, auto-
detect configuration options, and enhanced IP security with AES and Device DNA protection. These features provide a low-cost
programmable alternative to custom ASIC products with unprecedented ease-of-use. Spartan-6 FPGAs offer the best solution for high-
volume logic designs, consumer-oriented DSP designs, and cost-sensitive embedded applications. Spartan-6 FPGAs are the
programmable silicon foundation for Targeted Design Platforms that deliver integrated software and hardware components to enable
designers to focus on innovation as soon as their development cycle begins.
Summary of Spartan-6 FPGA Features
• Spartan-6 Family:
− Spartan-6 LX FPGA: Logic optimized
− Spartan-6 LXT FPGA: High-speed serial connectivity
• Designed for low cost
− Multiple efficient integrated blocks
− Optimized selection of I/O standards
− Staggered pads
− High volume plastic wire-bonded packages
• Low static and dynamic power
− 45 nm process optimized for cost and low power
− Hibernate power-down mode for zero power
− Suspend mode maintains state and configuration with
multi-pin wake-up, control enhancement
− Lower-power 1.0V core voltage (LX FPGAs, -1L only)
− High performance 1.2V core voltage (LX and LXT
FPGAs, -2 and -3 speed grades)
• Multi-voltage, multi-standard SelectIO banks
− Up to 1050 Mb/s data transfer rate per differential I/O
− Selectable output drive, up to 24 mA per pin
− 3.3V to 1.2V I/O standards and protocols
− Low-cost HSTL and SSTL memory interfaces
− Hot swap compliance
− Adjustable I/O slew rates to improve signal integrity
• High-speed GTP serial transceivers in the LXT FPGAs
− Up to 3.125 Gb/s
− High speed interfaces including: Serial ATA, Aurora,
1G Ethernet, PCI Express, OBSAI, CPRI, EPON,
GPON, DisplayPort, and XAUI
• Integrated Endpoint block for PCI Express designs (LXT)
• Low cost PCI® technology support compatible with the 32 bit,
33 MHz specification
• Efficient DSP48A1 slices
− High-performance arithmetic and signal processing
− Fast 18 x 18 multiplier and 48-bit accumulator
− Pipelining and cascading capability
− Pre-adder to assist filter applications
• Integrated Memory Controller blocks
−
DDR, DDR2, DDR3, and LPDDR support
− Data rates up to 800 Mb/s (12.8 Gb/s peak bandwidth)
− Multi-port bus structure with independent FIFO to reduce
design timing issues
• Abundant logic resources with increased logic capacity
− Optional shift register or distributed RAM support
− Efficient 6-input LUTs improve performance and
minimize power
− LUT with dual flip-flops for pipeline centric applications
• Block RAM with a wide range of granularity
− Efficient block RAM
− Fast block RAM with byte write enable
− 18 Kb blocks that can be optionally programmed as two
independent 9 Kb block RAMs
• Clock Management Tile (CMT) for enhanced performance
− Low noise, flexible clocking
− Digital Clock Managers (DCMs) eliminate clock skew
and duty cycle distortion
− Phase-Locked Loops (PLLs) for low-jitter clocking
− Frequency synthesis with simultaneous multiplication,
division, and phase shifting
− Sixteen low-skew global clock networks
• Simplified configuration, supports low-cost standards
− 2-pin auto-detect configuration
− Broad third-party SPI (up to x4) and NOR Flash support
− Feature rich Xilinx Platform Flash with JTAG
− MultiBoot support for remote upgrade with multiple
bitstreams, using watchdog protection
• Enhanced security for design protection
− Unique Device DNA identifier for design authentication
− AES bitstream encryption in the larger devices
• Faster embedded processing with enhanced, low cost,
MicroBlaze™ soft processor
• Industry-leading IP and reference designs
10
Spartan-6 Family Overview
DS160 (v1.2) June 24, 2009 Advance Product Specification
