The AMPMODU Mod IV & V interconnection system oers a wide variety of rugged and reliable
wire-to-board interconnections which mate to breakaway headers and shrouded headers that
are utilized to distribute low current signals throughout electronic equipment. Mod IV is ideal
for standard pressure applications with minimal vibrations. Mod V is ideal for high pressure
applications with high vibrations. Breakaway Headers oer a wide range of flexibility allowing
the customer to stock just one part number while allowing that customer to adjust the size of
the header needed. Shrouded Headers oer superior pin protection and come in both latching
and non latching configurations. Some are polarized to prevent misalignment.
Quick Reference Guide
AMPMODU MOD IV, V Interconnection System &
Shrouded & Breakaway Headers
FEATURES AND BENEFITS
• Categorized in two groups: board mount headers,
and cable to board receptacles
• Available in single and double row, vertical or right
angle, shrouded and breakaway
• Formed from high conductivity copper alloy
and selectively plated with gold for higher
performance and reliability
• Housings on all board-mounted assemblies are
made of high temperature tolerant materials and
incorporate stand-os for free drainage of flux
cleaning solutions
PRODUCT APPLICATIONS
• Medical Equipment
• Gaming Equipment
• Automotive Controls
• Servers
• Test/Measurement Devices
• Factory Automation
• Telecommunication Equipment
• Storage Equipment
• Vending
