ADM1270CP-EVALZ/
ADM1270RQ-EVALZ User Guide
UG-760
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel : 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluating the ADM1270 High Voltage Input Protection Device
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. A | Page 1 of 12
FEATURES
Controls supply voltages from 4 V to 60 V
Gate drive for low voltage drop reverse supply protection
Gate drive for P-channel field effect transistors (FETs)
Inrush current limiting control
Adjustable current limit
Foldback current limiting
Automatic retry or latch-off on current fault
Programmable current-limit timer for safe operating area (SOA)
Power-good and fault outputs
Analog undervoltage (UV) and overvoltage (OV) protection
16-lead, 3 mm × 3 mm LFCSP
16-lead QSOP
EVALUATION KIT CONTENTS
ADM1270CP-EVALZ or ADM1270RQ-EVALZ evaluation board
ADDITIONAL EQUIPMENT NEEDED
DC power supply
Multimeters for voltage and current measurements
Electronic or resistive loads
GENERAL DESCRIPTION
The ADM1270CP-EVALZ and ADM1270RQ-EVALZ evaluation
boards are used to demonstrate the functionality of the ADM1270
high voltage input protection device.
Full specifications on the ADM1270 are available in the product
data sheet, which should be consulted in conjunction with this
user guide when using these evaluation boards.
