This document contains complete and detailed description of all modules included in
the Atmel
®
AVR
®
XMEGA
®
D microcontroller family. The Atmel AVR XMEGA D is a
family of low-power, high-performance, and peripheral-rich CMOS 8/16-bit microcon-
trollers based on the AVR enhanced RISC architecture. The available Atmel AVR
XMEGA D modules described in this manual are:
•
Atmel AVR CPU
• Memories
• Event system
• System clock and clock options
• Power management and sleep modes
• System control and reset
• WDT - Watchdog timer
• Interrupts and programmable multilevel interrupt controller
• PORT - I/O ports
• TC - 16-bit timer/counter
• AWeX - Advanced waveform extension
• Hi-Res - High resolution extension
• RTC - Real-time counter
• TWI - Two-wire serial interface
• SPI - Serial peripheral interface
• USART - Universal synchronous and asynchronous serial receiver and transmitter
• IRCOM - Infrared communication module
• CRC - Cyclic redundancy check
• ADC - Analog-to-digital converter
• AC - Analog comparator
• PDI - Program and debug interface
• Memory programming
• Peripheral address map
• Register summary
• Interrupt vector summary
• Instruction set summary
8210C- AVR-09/11
8-bit Atmel
XMEGA D
Microcontroller
XMEGA D
MANUAL
