Rev. 0.1 5/10 Copyright © 2010 by Silicon Laboratories C8051F996-DK
C8051F996-DK
C8051F996 DEVELOPMENT KIT USER’S GUIDE
1. Relevant Devices
The C8051F996 Development Kit is intended as a development platform for the microcontrollers in the
C8051F99x-C8051F98x MCU family. The members of this MCU family are C8051F990, C8051F991, C8051F996,
C8051F997, C8051F980, C8051F981, C8051F982, C8051F983, C8051F985, C8051F986, C8051F987,
C8051F988, and C8051F989.
Notes:
The target board included in this kit is provided with a pre-soldered C8051F996 MCU (QSOP24 package).
Code developed on the C8051F996 can be easily ported to the other members of this MCU family.
Refer to the C8051F99x-C8051F98x data sheet for the differences between the members of this MCU family.
2. Kit Contents
The C8051F996 Development Kit contains the following items:
C8051F996 Target Board
C8051Fxxx Development Kit Quick-Start Guide
Silicon Laboratories IDE and Product Information CD-ROM. CD content includes the following:
Silicon Laboratories Integrated Development Environment (IDE)
Evaluation version of 8051 development tools (macro assembler, linker, C compiler)
Source code examples and register definition files
Documentation
C8051F996 Development Kit User’s Guide (this document)
Third Party Tools CD
AC to DC Power Adapter
USB Debug Adapter (USB to Debug Interface)
2 USB Cables
2 AAA Batteries
Figure 1. C8051F996 Target Board
