QSG136: CP2102N Mini Evaluation Kit
Quick-Start Guide
The CP2102N-MINIEK kit is designed to showcase the various
features of the CP2102N USBXpress® devices.
These highly-integrated USB-to-UART bridge controllers provide a simple solution for
updating RS-232 designs to USB using a minimum of components and PCB space. By
eliminating the need for complex firmware and driver development, the CP2102N devi-
ces enable quick USB connectivity with minimal development effort.
KIT CONTENTS
• CP2102N USB-to-UART Bridge Mini
Evaluation Board
• Getting Started card
J5
GND
TXD
RXD
CTS
VBUS
SUSPENDb
SUSPEND
RTS
GND
CHR0
J2
VDD
VDD
VREGIN
GPIO.0
GPIO.1
GPIO.2
GPIO.3
RSTb
CHREN
CHR1
