DAC290x-EVM
SBAU071B – JUNE 2001 – REVISED SEPTEMBER 2005
www.ti.com
DESCRIPTION
The DAC290x-EVM is designed for ease of use in evaluat-
ing the DAC290x dual, high-speed Digital-to-Analog Con-
verter (DAC) family. This family consists of three 125MSPS
DACs: the 10-bit DAC2900, the 12-bit DAC2902, and the
14-bit DAC2904. Due to its flexible design, the user can
evaluate the converter with different clock configurations,
independent bias control, internal or external reference source,
and single- or dual-supply operation. The analog output of
the DAC290x DACs can be configured to drive a 50Ω
terminated cable using a single-ended, or 4:1 or 1:1 imped-
ance ratio transformer.
FEATURES
● POPULATED EVALUATION BOARD FOR THE
DUAL, HIGH-SPEED DAC290x
● PROVIDES FAST AND EASY PERFORMANCE
TESTING FOR THE DAC290x
● SINGLE-ENDED OR TRANSFORMER-COUPLED
DIFFERENTIAL OUTPUTS
● SINGLE CLOCK INPUT CONFIGURATION
● ADJUSTABLE BIAS
