PRODUCTPREVIEW
F28M35H20B1, F28M35H20C1
F28M35H22B1, F28M35H22C1, F28M35H32B1, F28M35H32C1
F28M35H50B1, F28M35H50C1, F28M35H52B1, F28M35H52C1
www.ti.com
SPRS742D –JUNE 2011–REVISED AUGUST 2012
Concerto Microcontrollers
1 F28M35x ( Concerto™) MCUs
1.1 Features
12345
• Master Subsystem — ARM
®
Cortex™-M3 • Control Subsystem — TMS320C28x™ 32-Bit
CPU
– 100 MHz
– 150 MHz
– Embedded Memory
– Embedded Memory
• Up to 512KB Flash (ECC)
• Up to 512KB Flash (ECC)
• Up to 32KB RAM (ECC or Parity)
• Up to 36KB RAM (ECC or Parity)
• Up to 64KB Shared RAM
• Up to 64KB Shared RAM
• 2KB IPC Message RAM
• 2KB IPC Message RAM
– 5 Universal Asynchronous
Receiver/Transmitters (UARTs) – IEEE-754 Single-Precision Floating-Point
Unit (FPU)
– 4 Synchronous Serial Interfaces (SSIs)/
Serial Peripheral Interface (SPI) – Viterbi, Complex Math, CRC Unit (VCU)
– 2 Inter-integrated Circuits (I2Cs) – Serial Communications Interface (SCI)
– Universal Serial Bus On-the-Go (USB-OTG) + – Serial Peripheral Interface (SPI)
PHY
– Inter-integrated Circuit (I2C)
– 10/100 ENET 1588 MII
– 6-Channel Direct Memory Access (DMA)
– 2 Controller Area Networks (CANs)
– 9 Enhanced Pulse Width Modulator (ePWM)
– 32-Channel Direct Memory Access (µDMA) Modules
– Dual Security Zones (128-Bit Password per • 18 Outputs (16 High-Resolution)
Zone)
– 6 32-Bit Enhanced Capture (eCAP) Modules
– External Peripheral Interface (EPI)
– 3 32-Bit Enhanced Quadrature Encoder
– Micro Cyclic Redundancy Check (µCRC) (eQEP) Modules
Module
– Multichannel Buffered Serial Port (McBSP)
– 4 General-Purpose Timers
– External Peripheral Interface (EPI)
– 2 Watchdog Timer Modules
– One Security Zone (128-Bit Password)
– Endianness: Little Endian
– 3 32-Bit Timers
• Clocking
– Endianness: Little Endian
– On-chip Crystal Oscillator/External Clock
Input
• Analog Subsystem
– Dynamic PLL Ratio Changes Supported
– Dual 12-Bit Analog-to-Digital Converters
• 1.2-V Digital, 1.8-V Analog, 3.3-V I/O Design
(ADCs)
– Up to 2.88 MSPS
• Interprocessor Communications (IPC)
– Up to 20 Channels
– 32 Handshaking Channels
– 4 Sample-and-Hold (S/H) Circuits
– 4 Channels Generate IPC Interrupts
– Up to 6 Comparators With 10-Bit Digital-to-
– Can be Used to Coordinate Transfer of Data Analog Converter (DAC)
Through IPC Message RAMs
• Package
• Up to 74 Individually Programmable,
– 144-Pin RFP PowerPAD™ Thermally
Multiplexed GPIO Pins
Enhanced Thin Quad Flatpack (HTQFP)
– Glitch-free I/Os
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2Concerto, TMS320C28x, PowerPAD, C28x, C2000, Piccolo, Delfino, XDS are trademarks of Texas Instruments.
3Cortex is a trademark of ARM Limited.
4ARM is a registered trademark of ARM Ltd or its subsidiaries.
5All other trademarks are the property of their respective owners.
PRODUCT PREVIEW information concerns products in the formative or design phase of
Copyright © 2011–2012, Texas Instruments Incorporated
development. Characteristic data and other specifications are design goals. Texas
Instruments reserves the right to change or discontinue these products without notice.
