F28M35H52C, F28M35H22C, F28M35M52C, F28M35M22C, F28M35M20B, F28M35E20B
SPRS742I –JUNE 2011–REVISED JUNE 2015
F28M35x Concerto™ Microcontrollers
1 Device Overview
1.1 Features
1
• Master Subsystem — ARM
®
Cortex
®
-M3 • Control Subsystem — TMS320C28x 32-Bit CPU
– Up to 100 MHz – Up to 150 MHz
– Embedded Memory – C28x Core Hardware Built-in Self-Test
– Embedded Memory
• Up to 512KB of Flash (ECC)
• Up to 512KB of Flash (ECC)
• Up to 32KB of RAM (ECC or Parity)
• Up to 36KB of RAM (ECC or Parity)
• Up to 64KB of Shared RAM
• Up to 64KB of Shared RAM
• 2KB of IPC Message RAM
– Five Universal Asynchronous • 2KB of IPC Message RAM
Receiver/Transmitters (UARTs)
– IEEE-754 Single-Precision Floating-Point Unit
– Four Synchronous Serial Interfaces (SSIs) and (FPU)
a Serial Peripheral Interface (SPI)
– Viterbi, Complex Math, CRC Unit (VCU)
– Two Inter-integrated Circuits (I
2
Cs)
– Serial Communications Interface (SCI)
– Universal Serial Bus On-the-Go (USB-OTG) +
– SPI
PHY
– I
2
C
– 10/100 ENET 1588 MII
– 6-Channel Direct Memory Access (DMA)
– Two Controller Area Network, D_CAN, Modules
– Nine Enhanced Pulse Width Modulator (ePWM)
(Pin-Bootable)
Modules
– 32-Channel Micro Direct Memory Access
• 18 Outputs (16 High-Resolution)
(µDMA)
– Six 32-Bit Enhanced Capture (eCAP) Modules
– Dual Security Zones (128-Bit Password per
– Three 32-Bit Enhanced Quadrature Encoder
Zone)
Pulse (eQEP) Modules
– External Peripheral Interface (EPI)
– Multichannel Buffered Serial Port (McBSP)
– Micro Cyclic Redundancy Check (µCRC)
– EPI
Module
– One Security Zone (128-Bit Password)
– Four General-Purpose Timers
– Three 32-Bit Timers
– Two Watchdog Timer Modules
– Endianness: Little Endian
– Endianness: Little Endian
• Analog Subsystem
• Clocking
– Dual 12-Bit Analog-to-Digital Converters (ADCs)
– On-chip Crystal Oscillator and External Clock
– Up to 2.88 MSPS
Input
– Up to 20 Channels
– Dynamic Phase-Locked Loop (PLL) Ratio
– Four Sample-and-Hold (S/H) Circuits
Changes Supported
– Up to Six Comparators With 10-Bit Digital-to-
• 1.2-V Digital, 1.8-V Analog, 3.3-V I/O Design
Analog Converter (DAC)
• Interprocessor Communications (IPC)
• Package
– 32 Handshaking Channels
– 144-Pin RFP PowerPAD™ Thermally Enhanced
– Four Channels Generate IPC Interrupts
Thin Quad Flatpack (HTQFP)
– Can be Used to Coordinate Transfer of Data
• Temperature Options:
Through IPC Message RAMs
– T: –40ºC to 105ºC Junction
• Up to 74 Individually Programmable, Multiplexed
– S: –40ºC to 125ºC Junction
General-Purpose Input/Output (GPIO) Pins
– Q: –40ºC to 125ºC Free-Air
– Glitch-free I/Os
(Q100 Qualification for Automotive Applications)
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
