EK1HMC6350 User Guide
UG-1031
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Getting Started with the EK1HMC6350 Evaluation Kit and Software
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. 0 | Page 1 of 12
FEATURES
60 GHz evaluation kit designed for quick evaluation of the
HMC6300 and HMC6301 transmit/receive chipset
Demonstration platform allows easy integration of the
HMC6300 and HMC6301 radio link with a baseband
modem for over the air transmission
APPLICATIONS
Point to point millimeter wave radio development
Wireless Gigabyte Alliance/IEEE 802.11ad radio
60 GHz RF sniffing
60 GHz signal generator
Modem development
Radar/high resolution Imaging
EVALUATION KIT CONTENTS
1 HMC6300 Tx 60 GHz transmitter motherboard/module
assembly with a MMPX interface
1 HMC6301 Rx 60 GHz receiver motherboard/module
assembly with a MMPX interface
2 hand formable 2 inch coaxial cables with a male MMPX
connector on one end and a 1.85 mm male connector on
the other end
1 HMC6300 motherboard/TX module with crystal, USB
interface, supply regulators, MCX connector and
differential I/Q interface
1 HMC6301 motherboard/RX module with crystal, USB
interface, supply regulators, MCX connector and
differential I/Q interface
2 wall-mount power supplies
2 USB 2.0 male/male 6 foot cables
8 phase matched MCX to SMA cables for baseband interface
on both motherboards
Evaluation software CD-ROM containing the
HMC6300/HMC6301 Graphical User Interface software GUI
EQUIPMENT NEEDED
2 PCs, one designated for each motherboard for GUI control
Baseband source
Spectrum analyzer
DOCUMENTS NEEDED
HMC6300 data sheet
HMC6301 data sheet
GENERAL DESCRIPTION
The EK1HMC6350 evaluation kit allows users to set up a half-
duplex, 60 GHz millimeter wave link using standard baseband
analog interfaces. MMPX and 1.85 mm connectors are provided
to interface with third party test equipment or millimeter wave
antennas. The EK1HMC6350 evaluation kit includes a USB
interface and graphical user interface (GUI) software, the
HMC6300/HMC6301 Graphical User Interface, allowing the user
to program the HMC6300 and HMC6301 by writing to the device
registers.
There are two motherboards in the kit: an HMC6300 motherboard
with the TX module location populated and the HMC6301
motherboard with the RX module location populated.
Full specifications on the HMC6300 and HMC6301 are available in
the HMC6300 and HMC6301 data sheets, which should be
consulted in conjunction with this user guide when working
with the evaluation board.
