Application Note 1455
ISL34341 and ISL76321 Evaluation Kit User Manual
Overview
This manual covers both the ISL34341 and ISL76321
evaluation kits. These kits enable the user to exercise the
SerDes in a lab environment and to see the high speed and
parallel signals conveniently on an oscilloscope. Contents of
the kit are shown in Figure 1.
Schematics and a software GUI can be downloaded from:
http://www.intersil.com/data/EV/ISL34341_Eval_Kit_Software.zip
There are slight differences between the ISL34341 and
ISL76321 kits. The ISL76321 uses a Molex cable instead of
Rosenberger which the ILS34341 uses. Unless specifically
mentioned, ISL76321 can be substituted anywhere you see
ISL34341.
FIGURE 1. KIT CONTENTS
CAT5 CABLES FOR POWER
AN D I
2
C TO EVBS
ROSENBERGER
CABLE FOR HS
SERIAL TRAFFIC
USB CABLE TO
PC
DESERIALIZER EVB
INTERFACE BOARD
S
ERIALIZER EVB
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
