© Semiconductor Components Industries, LLC, 2014
September, 2014 − Rev. 0
1 Publication Order Number:
EVBUM2255/D
TOUCH/LRACOMBOGEVB
TOUCH/LRACOMBOGEVB
Evaluation Board
User's Manual
Scope
The TOUCH/LRACOMBOGEVB demo showcases
ON Semiconductor’s High-Accuracy Capacitive Touch
Sensor (LC717A10AR) along with Linear Vibrator Driver
(LC898301XA) for haptic feedback and an 8-bit
Microcontroller (LC87F1M16A). The following is an
instruction manual for the operation of this evaluation
board.
Necessary Equipment
• 1 Mini-B USB Cable with PC (Figure 1) or
• 1 AC to DC 5 V USB Adapter (Figure 2)
Figure 1. Mini-B USB Cable
Figure 2. USB Adapter
Overview
Microcontroller (LC87F1M16A) distinguishes the keys
of Touch Switch (LC717A10AR) by using I
2
C and control
the actuator of Haptics (LC898301XA), LED and speaker.
The power supply is supplied from USB.
Figure 3. Board with USB Cable
http://onsemi.com
EVAL BOARD USER’S MANUAL
