June 2007 Rev 2 1/33
UM0313
User manual
EK302DL
Evaluation Kit
Introduction
The EK302DL is an evaluation kit designed to provide the user with a complete, ready-to-
use platform for evaluation of the LIS302DL. The LIS302DL is a low power 3-axis linear
accelerometer with digital output. The device includes a sensing element and an IC
interface capable of translating information from the sensing element into a measured signal
that can be used for external applications.
In addition to the MEMS sensor, the evaluation board utilizes an ST7-USB microcontroller
which functions as a bridge between the sensor and the PC, on which it is possible to use
the Graphical User Interface included with the kit or dedicated software routines for
customized applications.
This user manual describes the hardware included with the evaluation kit and provides the
information required to install and run the evaluation kit user interface.
For details regarding the features of the LIS302DL sensor, please refer to the datasheet for
this device and application note AN2335.
www.st.com
