User's Guide
SNVU424–August 2014
LM43600PWPEVM User Guide
Introduction
The Texas Instruments LM43600PWPEVM evaluation module (EVM) helps designers evaluate the
operation and performance of the LM43600 wide-input voltage Simple Switcher
®
buck regulator. The
device offers configurability in a 1 V to 28 V output voltage, synchronous rectification and a 200 kHz to 2.2
MHz adjustable frequency range. It also offers external frequency synchronization, power good (PG) flag,
and a precision enable to program undervoltage lockout (UVLO) and internal compensation. The
LM43600PWPEVM is configured for an output voltage of 3.3 V and a switching frequency of 500 kHz.
Refer to the LM43600 datasheet for additional features, detailed description and available options.
The EVM contains one DC-DC converter (See Table 1).
Table 1. Device and Package Configurations
CONVERTER IC PACKAGE
U1 LM43600 (PWP) HTSSOP-16
Setup
This section describes the test points and connectors on the EVM and how to properly connect, set up
and use the . Please refer to Figure 1 for a top view of the EVM and relative placement of
theLM43600PWPEVM different test points and edge connector.
1
SNVU424–August 2014 LM43600PWPEVM User Guide
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
