An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
MSP430FR5739
,
MSP430FR5738
,
MSP430FR5737
,
MSP430FR5736
,
MSP430FR5735
MSP430FR5734, MSP430FR5733, MSP430FR5732, MSP430FR5731, MSP430FR5730
SLAS639K –JULY 2011–REVISED APRIL 2016
MSP430FR573x Mixed-Signal Microcontrollers
1 Device Overview
1
1.1 Features
1
• Embedded Microcontroller
– 16-Bit RISC Architecture up to 24-MHz Clock
– Wide Supply Voltage Range (2 V to 3.6 V)
– –40°C to 85°C Operation
• Optimized Ultra-Low-Power Modes
– Active Mode: 81.4 µA/MHz (Typical)
– Standby (LPM3 With VLO): 6.3 µA (Typical)
– Real-Time Clock (RTC) (LPM3.5 With Crystal):
1.5 µA (Typical)
– Shutdown (LPM4.5): 0.32 µA (Typical)
• Ultra-Low-Power Ferroelectric RAM (FRAM)
– Up to 16KB of Nonvolatile Memory
– Ultra-Low-Power Writes
– Fast Write at 125 ns per Word (16KB in 1 ms)
– Built-In Error Correction Coding (ECC) and
Memory Protection Unit (MPU)
– Universal Memory = Program + Data + Storage
– 10
15
Write Cycle Endurance
– Radiation Resistant and Nonmagnetic
• Intelligent Digital Peripherals
– 32-Bit Hardware Multiplier (MPY)
– Three-Channel Internal DMA
– Real-Time Clock (RTC) With Calendar and
Alarm Functions
– Five 16-Bit Timers With up to Three
Capture/Compare Registers
– 16-Bit Cyclic Redundancy Checker (CRC)
• High-Performance Analog
– 16-Channel Analog Comparator With Voltage
Reference and Programmable Hysteresis
– 14-Channel 10-Bit Analog-to-Digital Converter
(ADC) With Internal Reference and Sample-and-
Hold
• 200 ksps at 100-µA Consumption
• Enhanced Serial Communication
– eUSCI_A0 and eUSCI_A1 Support:
• UART With Automatic Baud-Rate Detection
• IrDA Encode and Decode
• SPI at Rates up to 10 Mbps
– eUSCI_B0 Supports:
• I
2
C With Multiple-Slave Addressing
• SPI at Rates up to 10 Mbps
– Hardware UART Bootloader (BSL)
• Power Management System
– Fully Integrated LDO
– Supply Voltage Supervisor for Core and Supply
Voltages With Reset Capability
– Always-On Zero-Power Brownout Detection
– Serial Onboard Programming With No External
Voltage Needed
• Flexible Clock System
– Fixed-Frequency DCO With Six Selectable
Factory-Trimmed Frequencies (Device
Dependent)
– Low-Power Low-Frequency Internal Clock
Source (VLO)
– 32-kHz Crystals (LFXT)
– High-Frequency Crystals (HFXT)
• Development Tools and Software
– Free Professional Development Environment
(Code Composer Studio™ IDE)
– Low-Cost Full-Featured Kit
(MSP-EXP430FR5739)
– Full Development Kit (MSP-FET430U40A)
– Target Board (MSP-TS430RHA40A)
• Family Members
– See Table 3-1 for Available Device Variants and
Packages
– For Complete Module Descriptions, See the
MSP430FR57xx Family User's Guide
1.2 Applications
• Home Automation
• Security
• Sensor Management
• Data Acquisition
CAUTION These products use FRAM nonvolatile memory technology. FRAM retention is sensitive to extreme temperatures,
such as those experienced during reflow or hand soldering. See Absolute Maximum Ratings for more information.
CAUTION System-level ESD protection must be applied in compliance with the device-level ESD specification to prevent
electrical overstress or disturb of data or code memory. See the application report MSP430™ System-Level ESD
Considerations (SLAA530) for more information.
