An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
MSP430FR6989
,
MSP430FR69891
,
MSP430FR6988
,
MSP430FR6987
MSP430FR5989, MSP430FR59891, MSP430FR5988, MSP430FR5987, MSP430FR5986
SLAS789C –JUNE 2014–REVISED MARCH 2017
MSP430FR698x(1), MSP430FR598x(1) Mixed-Signal Microcontrollers
1 Device Overview
1
1.1 Features
1
(1) Minimum supply voltage is restricted by SVS levels.
(2) RTC is clocked by a 3.7-pF crystal.
• Embedded Microcontroller
– 16-Bit RISC Architecture up to 16-MHz Clock
– Wide Supply Voltage Range (1.8 V to 3.6 V)
(1)
• Optimized Ultra-Low-Power Modes
– Active Mode: Approximately 100 µA/MHz
– Standby (LPM3 With VLO): 0.4 µA (Typical)
– Real-Time Clock (RTC) (LPM3.5): 0.35 µA
(Typical)
(2)
– Shutdown (LPM4.5): 0.02 µA (Typical)
• Ultra-Low-Power Ferroelectric RAM (FRAM)
– Up to 128KB of Nonvolatile Memory
– Ultra-Low-Power Writes
– Fast Write at 125 ns per Word (64KB in 4 ms)
– Unified Memory = Program + Data + Storage in
One Single Space
– 10
15
Write Cycle Endurance
– Radiation Resistant and Nonmagnetic
• Intelligent Digital Peripherals
– 32-Bit Hardware Multiplier (MPY)
– Three-Channel Internal Direct Memory Access
(DMA)
– RTC With Calendar and Alarm Functions
– Five 16-Bit Timers With up to 7
Capture/Compare Registers Each
– 16-Bit and 32-Bit Cyclic Redundancy Checker
(CRC16, CRC32)
• High-Performance Analog
– Extended Scan Interface (ESI) for Background
Water, Heat, and Gas Volume Measurement
– 16-Channel Analog Comparator
– 12-Bit Analog-to-Digital Converter (ADC) With
Internal Reference and Sample-and-Hold and
up to 16 External Input Channels
– Integrated LCD Driver With Contrast Control for
up to 320 Segments
• Multifunction Input/Output Ports
– All P1 to P10 and PJ Pins Support Capacitive
Touch Capability Without Need for External
Components
– Accessible Bit-, Byte- and Word-Wise (in Pairs)
– Edge-Selectable Wakeup From LPM on Ports
P1, P2, P3, and P4
– Programmable Pullup and Pulldown on All Ports
• Code Security and Encryption
– 128-Bit or 256-Bit AES Security Encryption and
Decryption Coprocessor
– True Random Number Seed for Random
Number Generation Algorithm
• Enhanced Serial Communication
– eUSCI_A0 and eUSCI_A1 Support:
– UART With Automatic Baud-Rate Detection
– IrDA Encode and Decode
– SPI
– eUSCI_B0 and eUSCI_B1 Support:
– I
2
C With Multiple-Slave Addressing
– SPI
– Hardware UART and I
2
C Bootloader (BSL)
• Flexible Clock System
– Fixed-Frequency DCO With 10 Selectable
Factory-Trimmed Frequencies
– Low-Power Low-Frequency Internal Clock
Source (VLO)
– 32-kHz Crystals (LFXT)
– High-Frequency Crystals (HFXT)
• Development Tools and Software
– Free Professional Development Environments
With EnergyTrace++ ™ Technology
– Experimenter and Development Kits
• Family Members
– Device Comparison Summarizes the Device
Variants and Available Packages Types
• For Complete Module Descriptions, See the
MSP430FR58xx, MSP430FR59xx,
MSP430FR68xx, and MSP430FR69xx Family
User's Guide
