www.honeywell.com/sensing 1
Heavy Duty products. Built for the toughest applications.
Honeywell Sensing and Control (S&C) offers decades of
experience in the heavy duty pressure products industry.
That’s why, industry-wide, our heavy duty pressure sensors
and transducers are known for enhanced quality, reliability,
and service – which adds up to outstanding value for your
applications.
Heavy Duty Pressure Sensors are small, allowing them to be
used on their own in tight packages or as the building block for
a complete transducer. The 13 mm Series and the 19 mm Series
were developed for potential use in pressure applications that
involve measurement of hostile media in harsh environments
FEATURES
HEAVY DUTY PRESSURE
SENSORS
13 mm Series.
Features: Rugged, isolated stainless steel
package • Accommodates media that will
not adversely affect 316L stainless steel
• Based on reliable semiconductor
technology • Calibrated and temperature
compensated • Voltage or current supply
options • Absolute and sealed gage
pressures • For potential applications from
500 psi to 5,000 psi
Benets: Used in high pressure potential
applications involving measurement of
hostile media in harsh environments.
Piezoresistive semiconductor sensor chip
in oil-isolated housing with or without
an integral ceramic for temperature
compensation and calibration is designed
to provide reliable, stable, and accurate
performance. Weld-ring collar and special
back support ring for enhanced cycle
life capability as well as further package
integration in OEM applications. Potential
applications include industrial and
Heavy Duty
Pressure Sensors/
Transducers Line
Guide
continued on page 4
hydraulic controls, tank pressure, pressure
transmitters, and process control systems.
19 mm Series.
Features: Rugged, isolated stainless steel
package • Accommodates media that will
not adversely affect 316L stainless steel
• Small size • Based on reliable
semiconductor technology • Absolute and
gage pressures • Vacuum compatible,
isolated sensors • Calibrated and
temperature compensated (some listings)
• For potential applications up to 500 psi
Benets: Variety of pressure connections
allow use in wide range of OEM
equipment. Uncompensated version
for use in potential applications using
specialized circuit designs. Rugged
for use in potential applications where
corrosive liquids or gases are monitored
and may also be exposed to a vacuum
such as industrial controls, process control
systems, industrial automation and flow
control, and pressure calibrators.
HEAVY DUTY PRESSURE
TRANSDUCERS
PX2 Series.
Features: Designed for configurability
• Cost-effective • Application expertise
• Global support • Industry-leading Total
Error Band (TEB) • Durable • Designed to
Six Sigma standards • Energy efcient
• Broad compensated temperature range
• Good EMC protection
Benets: Numerous standard or
custom connectors, ports, pressure
types and ranges, and output options
allow configuration to meet specific
application needs, quick availability of
product samples, and reduce design
and implementation costs of the end
product. Honeywell’s knowledgeable
application engineers are available to
answer specific design questions during
the development, launch, and production
of the customers’ product. Honeywell’s
global presence offers immediate product
and application support throughout the
compatible with 316 stainless steel, a type of steel that
increases corrosion resistance, improves resistance to pitting
from chloride ion solutions, and provides increased strength at
high temperatures.
Heavy Duty Pressure Transducers are complete amplified
and compensated pressure measurement solutions. With a
choice of ports, connectors, outputs and pressure ranges,
the PX2 Series, MLH Series and SPT Series transducers can
be configured to meet the needs of the application. They are
engineered to be resistant to a wide variety of media for use in
most harsh environments.
