August 2008 Rev 2 1/41
41
UM0482
User manual
STM8/128-EVAL
evaluation board
Introduction
The STM8S2xx evaluation board STM8/128-
EVAL is designed as a complete development
platform for STMicroelectronic's STM8 core-
based STM8S2xx microcontroller with
CAN2.0A/B compliant interface, I
2
C, SPI, two
UART channels with smartcard, IrDA and LIN
support, internal 2 Kbyte data Flash and
128 Kbyte code Flash, SWIM debugging support.
The full range of hardware features on the board
is able to help you evaluate all peripherals
(including motor control, CAN, MicroSD card,
smartcard, UART, LIN, IrDA) and develop your
own applications. Extension headers make it
possible to easily connect a daughter board or
wrapping board for your specific application.
Features
■ Two 5 V power supply options: power jack or
daughter board
■ Audio play and record
■ 64 or 128 Mbyte MicroSD card
■ Both A&B type smartcard support
■ 64 Kbit I
2
C EEPROM
■ 2 channels of RS-232 communication
■ IrDA transceiver
■ 2 channels of LIN communication
■ CAN2.0A/B compliant connection
■ Inductor motor control connector
■ SWIM and STice debug support
■ 122x32 dot-matrix serial interface LCD module
■ Joystick with 4-direction control and selector
■ Reset, Wakeup, Tamper and User button
■ 4 LEDs
■ Extension connector for daughter board or
wrapping board.
Figure 1. STM8/128-EVAL evaluation board
www.st.com
