This is information on a product in full production.
August 2017 DocID5286 Rev 8 1/27
TL1431
Programmable voltage reference
Datasheet
-
production data
Features
• Adjustable output voltage: V
REF
to 36 V
• Sink current capability: 1 to 100 mA
• Typical output impedance: 0.22
• 0.4% and 0.25% voltage precision
• Automotive temp. range - 40 °C to +125 °C
Description
The TL1431 is a programmable shunt voltage
reference with guaranteed temperature stability
over the entire operating temperature range.
The output voltage may be set to any value
between 2.5 V and 36 V with two external
resistors.
The TL1431 operates with a wide current range
from 1 to 100 mA with a typical dynamic
impedance of 0.2 .
Z
TO-92
(Plastic package)
L
SOT23-3L
C
SOT323-6L
D
SO-8
(Batwing plastic micropackage)
L
SOT23-5L
www.st.com
