An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCT PREVIEW Information. Product in design phase of
development. Subject to change or discontinuance without notice.
TMS570LC4357
SPNS195B –FEBRUARY 2014–REVISED JANUARY 2016
TMS570LC4357 Hercules™ Microcontroller Based on the ARM® Cortex®-R Core
1 Device Overview
1
1.1 Features
1
• High-Performance Automotive-Grade
Microcontroller for Safety-Critical Applications
– Dual-Core Lockstep CPUs With ECC-Protected
Caches
– ECC on Flash and RAM Interfaces
– Built-In Self-Test (BIST) for CPU, High-End
Timers, and On-Chip RAMs
– Error Signaling Module (ESM) With Error Pin
– Voltage and Clock Monitoring
• ARM
®
Cortex
®
- R5F 32-Bit RISC CPU
– 1.66 DMIPS/MHz With 8-Stage Pipeline
– FPU With Single- and Double-Precision
– 16-Region Memory Protection Unit (MPU)
– 32KB of Instruction and 32KB of Data Caches
With ECC
– Open Architecture With Third-Party Support
• Operating Conditions
– Up to 300-MHz CPU Clock
– Core Supply Voltage (VCC): 1.14 to 1.32 V
– I/O Supply Voltage (VCCIO): 3.0 to 3.6 V
• Integrated Memory
– 4MB of Program Flash With ECC
– 512KB of RAM With ECC
– 128KB of Data Flash for Emulated EEPROM
With ECC
• 16-Bit External Memory Interface (EMIF)
• Hercules™ Common Platform Architecture
– Consistent Memory Map Across Family
– Real-Time Interrupt (RTI) Timer (OS Timer)
– Two 128-Channel Vectored Interrupt Modules
(VIMs) With ECC Protection on Vector Table
• VIM1 and VIM2 in Safety Lockstep Mode
– Two 2-Channel Cyclic Redundancy Checker
(CRC) Modules
• Direct Memory Access (DMA) Controller
– 32 Channels and 48 Peripheral Requests
– ECC Protection for Control Packet RAM
– DMA Accesses Protected by Dedicated MPU
• Frequency-Modulated Phase-Locked Loop
(FMPLL) With Built-In Slip Detector
• Separate Nonmodulating PLL
• IEEE 1149.1 JTAG, Boundary Scan, and ARM
CoreSight™ Components
• Advanced JTAG Security Module (AJSM)
• Trace and Calibration Capabilities
– ETM™, RTP, DMM, POM
• Multiple Communication Interfaces
– 10/100 Mbps Ethernet MAC (EMAC)
• IEEE 802.3 Compliant (3.3-V I/O Only)
• Supports MII, RMII, and MDIO
– FlexRay Controller With 2 Channels
• 8KB of Message RAM With ECC Protection
• Dedicated FlexRay Transfer Unit (FTU)
– Four CAN Controller (DCAN) Modules
• 64 Mailboxes, Each With ECC Protection
• Compliant to CAN Protocol Version 2.0B
– Two Inter-Integrated Circuit (I
2
C) Modules
– Five Multibuffered Serial Peripheral Interface
(MibSPI) Modules
• MibSPI1: 256 Words With ECC Protection
• Other MibSPIs: 128 Words With ECC
Protection
– Four UART (SCI) Interfaces, Two With Local
Interconnect Network (LIN 2.1) Interface
Support
• Two Next Generation High-End Timer (N2HET)
Modules
– 32 Programmable Channels Each
– 256-Word Instruction RAM With Parity
– Hardware Angle Generator for Each N2HET
– Dedicated High-End Timer Transfer Unit (HTU)
for Each N2HET
• Two 12-Bit Multibuffered Analog-to-Digital
Converter (MibADC) Modules
– MibADC1: 32 Channels Plus Control for up to
1024 Off-Chip Channels
– MibADC2: 25 Channels
– 16 Shared Channels
– 64 Result Buffers Each With Parity Protection
• Enhanced Timing Peripherals
– 7 Enhanced Pulse Width Modulator (ePWM)
Modules
– 6 Enhanced Capture (eCAP) Modules
– 2 Enhanced Quadrature Encoder Pulse (eQEP)
Modules
• Three On-Die Temperature Sensors
• Up to 145 Pins Available for General-Purpose I/O
(GPIO)
• 16 Dedicated GPIO Pins With External Interrupt
Capability
• Packages
– 337-Ball Grid Array (ZWT) [Green]
