1 Introduction
1.1 Specification
User's Guide
SLVU203 – March 2007
TPS65165EVM-233
The TPS65165EVM-233 takes a 2.5-V to 6-V input rail and provides the three
bias-supply voltages and three integrated opamps that are required for TV and monitor
TFT-LCD panels. The TPS65165EVM-233 has one boost converter with an integrated
low-side FET, one negative charge-pump controller requiring external Schottky diodes,
and one fully-integrated positive charge pump. External passive components to support
the boost converter include inductors and capacitors, and external components for the
charge pumps include capacitors.
Contents
1 Introduction .......................................................................................... 1
2 Setup and Test Results ............................................................................ 2
3 Board Layout ........................................................................................ 5
4 Schematic and Bill of Materials ................................................................... 8
List of Figures
1 Startup Waveform .................................................................................. 4
2 Layout Recommendation .......................................................................... 5
3 Top Assembly ....................................................................................... 6
4 Top Layer ............................................................................................ 6
5 Bottom Layer ........................................................................................ 7
List of Tables
1 Performance Specification Summary ............................................................ 1
2 Default Jumper Settings ........................................................................... 2
3 Bill of Materials ...................................................................................... 9
This chapter contains background information for the TPS65165EVM-233 evaluation module.
Table 1 provides a summary of the TPS65165EVM-233 performance specifications. All specifications are
given for an ambient temperature of 25 ° C.
Table 1. Performance Specification Summary
Voltage Range (V) Current Range (mA)
Specification
Min Typ Max Min Typ Max
VIN 4.5 5 5.5 5000
Vs 14.7 15 15.3 1000
VGL –5.15 –5 –4.85 50
VGH 23.0 23.8
(1)
24.5 50
(1)
Assumes that SUP = V
S
.
