Issue 1 – December 2008 www.zetex.com
© Diodes Incorporated 2008 www.diodes.com
1 of 6
ZXMS6004EV1 USER GUIDE
Device features
• Compact high power dissipation package
• Short circuit protection
• Thermal shutdown with auto restart
• Over voltage protection (active clamping)
• Load dump protection (actively protect
load)
• Input ESD protection
• 3.3V and 5V logic level input
• Low input current
• 1.3A continuous current rating
Ordering Information
Evaluation board order number
ZXMS6004EV1
Device order number
ZXMS6004FFTA
Description
The ZXMS6004EV1 board (Figure 1) is
intended for the evaluation of the
ZXMS6004FF self protected low side
MOSFET. The evaluation board enables the
user to evaluate the over-temperature, over-
current and over-voltage (active clamp)
features of the ZXMS6004FF. Furthermore,
this evaluation board allows the user to
compare the performance of the
ZXMS6004FF, which is packaged, in the
SOT23 Flat package, against the much larger
SOT223 footprint devices (BSP75G)
Figure 1 Evaluation board layout
