74ACT715, 74ACT715-R Programmable Video Sync Generator
April 2007
©1988 Fairchild Semiconductor Corporation www.fairchildsemi.com
74ACT715, 74ACT715-R Rev. 1.3
74ACT715, 74ACT715-R
Programmable Video Sync Generator
Features
■
Maximum Input Clock Frequency
>
130MHz
■
Interlaced and non-interlaced formats available
■
Separate or composite horizontal and vertical Sync
and Blank signals available
■
Complete control of pulse width via register
programming
■
All inputs are TTL compatible
■
8mA drive on all outputs
■
Default RS170/NTSC values mask programmed into
registers
■
ACT715-R is mask programmed to default to a Clock
Enable state for easier start-up into 14.31818MHz
RS170 timing
General Description
The ACT715 and ACT715-R are 20-pin TTL-input
compatible devices capable of generating Horizontal,
Vertical and Composite Sync and Blank signals for tele-
visions and monitors. All pulse widths are completely
definable by the user. The devices are capable of gener-
ating signals for both interlaced and noninterlaced
modes of operation. Equalization and serration pulses
can be introduced into the Composite Sync signal when
needed.
Four additional signals can also be made available when
Composite Sync or Blank are used. These signals can
be used to generate horizontal or vertical gating pulses,
cursor position or vertical Interrupt signal.
These devices make no assumptions concerning the
system architecture. Line rate and field/frame rate are all
a function of the values programmed into the data regis-
ters, the status register, and the input clock frequency.
The ACT715 is mask programmed to default to a Clock
Disable state. Bit 10 of the Status Register, Register 0,
defaults to a logic “0”. This facilitates (re)programming
before operation.
The ACT715-R is the same as the ACT715 in all
respects except that the ACT715-R is mask pro-
grammed to default to a Clock Enabled state. Bit 10 of
the Status Register defaults to a logic “1”. Although
completely (re)programmable, the ACT715-R version is
better suited for applications using the default
14.31818MHz RS-170 register values. This feature
allows power-up directly into operation, following a single
CLEAR pulse.
Ordering Information
Device also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering number.
Order Number
Package
Number Package Description
74ACT715SC M20B 20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
74ACT715-RSC M20B 20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
