Features
• High-performance, Low-power 32-bit Atmel
®
AVR
®
Microcontroller
– Compact Single-cycle RISC Instruction Set Including DSP Instructions
– Read-modify-write Instructions and Atomic Bit Manipulation
– Performance
• Up to 64DMIPS Running at 50MHz from Flash (1 Flash Wait State)
• Up to 36DMIPS Running at 25MHz from Flash (0 Flash Wait State)
– Memory Protection Unit (MPU)
• Secure Access Unit (SAU) providing User-defined Peripheral Protection
• picoPower
®
Technology for Ultra-low Power Consumption
• Multi-hierarchy Bus System
– High-performance Data Transfers on Separate Buses for Increased Performance
– 12 Peripheral DMA Channels Improve Speed for Peripheral Communication
• Internal High-speed Flash
– 256Kbytes and 128Kbytes Versions
– Single-cycle Access up to 25MHz
– FlashVault Technology Allows Pre-programmed Secure Library Support for End
User Applications
– Prefetch Buffer Optimizing Instruction Execution at Maximum Speed
– 100,000 Write Cycles, 15-year Data Retention Capability
– Flash Security Locks and User-defined Configuration Area
• Internal High-speed SRAM, Single-cycle Access at Full Speed
–32Kbytes
• Interrupt Controller (INTC)
– Autovectored Low-latency Interrupt Service with Programmable Priority
• External Interrupt Controller (EIC)
• Peripheral Event System for Direct Peripheral to Peripheral Communication
• System Functions
– Power and Clock Manager
– SleepWalking Power Saving Control
– Internal System RC Oscillator (RCSYS)
– 32 KHz Oscillator
– Multipurpose Oscillator, Phase Locked Loop (PLL), and Digital Frequency Locked
Loop (DFLL)
• Windowed Watchdog Timer (WDT)
• Asynchronous Timer (AST) with Real-time Clock Capability
– Counter or Calendar Mode Supported
• Frequency Meter (FREQM) for Accurate Measuring of Clock Frequency
• Six 16-bit Timer/Counter (TC) Channels
– External Clock Inputs, PWM, Capture, and Various Counting Capabilities
• PWM Channels on All I/O Pins (PWMA)
– 8-bit PWM with a Source Clock up to 150MHz
• Four Universal Synchronous/Asynchronous Receiver/Transmitters (USART)
– Independent Baudrate Generator, Support for SPI
– Support for Hardware Handshaking
• One Master/Slave Serial Peripheral Interface (SPI) with Chip Select Signals
– Up to 15 SPI Slaves can be Addressed
32145CS–06/2013
32-bit Atmel
AVR
Microcontroller
AT32UC3L0256
AT32UC3L0128
Summary
